4. Combination Table4. Combination Table
HEATING
Outdoor unit A B C
Heating
Capacity
Capacity
Power
Consumption
Current Efc. NOM.
Heating.
At 7℃/20℃
SEASONAL
EFFICIENCY
(ACCORDING
EN14825)
SCOP
P
design
Qhe
W W W A
A B C MIN STD MAX MIN STD MAX MIN STD MAX COP Class kW kWh
AJ068TXJ3KG/EU
2 Unit
7 7 2200 2200 1400 4400 5060 380 1150 1600 1.9 4.9 7. 3 3.83 A+ 4.25 3.05 1006
7 9 2200 3300 1400 5500 6330 380 1400 2000 1.9 6.0 9.2 3.93 A+ 4.2 4.21 1401
7 12 2200 4000 1400 6200 7130 380 1590 2300 1.9 6.8 10.5 3.90 A+ 4.17 4.52 1517
7 18 2090 5710 1400 7800 8970 380 1880 2700 1.9 8.5 12.4 4.14 A+ 4.26 5.65 1856
9 9 3300 3300 1400 6600 7590 380 1770 2600 1.9 7. 5 11.9 3.73 A+ 4.22 4.91 1628
9 12 3300 4000 1400 7300 8400 380 1870 2600 1.9 8.0 11.9 3.90 A+ 4.19 5.09 1699
9 18 2770 5030 1400 7800 8970 380 1940 2800 1.9 8.7 12.8 4.02 A+ 4.23 5.09 1683
12 12 3900 3900 1400 7800 8970 380 1910 2700 1.9 8.6 12.4 4.08 A+ 4.27 5.09 1668
12 18 3200 4800 1400 8000 9200 380 1990 2800 1.9 9.0 12.8 4.02 A+ 4.23 5.09 1683
18 18 4000 4000 1400 8000 9200 380 1980 2800 1.9 8.9 12.8 4.04 A+ 4.28 5.65 1847
3 Unit
7 7 7 2200 2200 2200 1400 6600 8100 380 1540 2400 1.9 6.6 11.0 4.28 A+ 4.24 5.65 1867
7 7 9 2200 2200 3300 1400 7700 9500 380 1780 2500 1.9 8.1 11.4 4.32 A+ 4.24 5.65 1867
7 7 12 2100 2100 3800 1400 8000 9800 380 1870 2600 1.9 8.5 11.9 4.28 A+ 4.26 5.65 1856
7 7 18 1690 1690 4620 1400 8000 9800 380 1860 2600 1.9 8.4 11.9 4.30 A+ 4.26 5.65 1856
7 9 9 2000 3000 3000 1400 8000 9800 380 1810 2500 1.9 8.2 11.4 4.42 A+ 4.32 5.65 1833
7 9 12 1850 2780 3370 1400 8000 9800 380 1830 2600 1.9 8.3 11.9 4.37 A+ 4.24 5.65 1867
7 9 18 1530 2300 4170 1400 8000 9800 380 1860 2600 1.9 8.4 11.9 4.30 A+ 4.24 5.65 1867
7 12 12 1720 3140 3140 1400 8000 9800 380 1860 2600 1.9 8.4 11.9 4.30 A+ 4.24 5.65 1867
7 12 18 1450 2620 3930 1400 8000 9800 380 1860 2600
1.9 8.4 11.9 4.30 A+ 4.24 5.65 1867
9 9 9 2660 2670 2670 1400 8000 9800 380 1850 2600 1.9 8.4 11.9 4.32 A+ 4.24 5.65 1867
9 9 12 2490 2490 3020 1400 8000 9800 380 1850 2600 1.9 8.4 11.9 4.32 A+ 4.26 5.65 1856
9 9 18 2100 2100 3800 1400 8000 9800 380 1870 2600 1.9 8.5 11.9 4.28 A+ 4.26 5.65 1856
9 12 12 2340 2830 2830 1400 8000 9800 380 1870 2600 1.9 8.5 11.9 4.28 A+ 4.24 5.65 1867
9 12 18 1980 2410 3610 1400 8000 9800 380 1890 2700 1.9 8.6 12.4 4.23 A+ 4.24 5.65 1867
12 12 12 2660 2670 2670 1400 8000 9800 380 1810 2600 1.9 8.2 11.9 4.42 A+ 4.32 5.65 1833
NOTE
1
EER and COP declared only for the purpose of tax deductions in force at the time of the creation of this catalog.
2
The above is the value for connecting with the following indoor units.
- Wind Free(PRM) : AR07TXCAAWK, AR09TXCAAWK, AR12TXCAAWK
3
You can not connect a single unit.
4
Power consumption include indoor unit power.
