Samsung AR09TXEAAWKNEU - Page 63

63
5. Dimensional Drawing
5-1. Outdoor units
 AJ100TXJ5KG/EU
Unit : mm [inches]
Rear View
Power & Communication
Wiring conduit
Detail for Service valve position
940 [37]
620 [24-7/16]
360 [14-3/16]
384 [15-1/8]
330 [13]
998 [39-5/16]
973 [38-5/16]
25 [1]
95 [3-3/4] 183 [7-3/16]
218 [8-5/8]
392 [15-7/16]
375 [14-3/4]
310 [12-3/16]
245 [9-5/8]
180 [7-1/16]
19 [3/4]
40 [1-9/16]
115 [1-1/2] 82 [3-1/4]
147 [5-3/4]
212 [8-5/16]
277 [10-15/16]
342 [13-1/2]
30 [1-3/16]
NO Name Description
1
Refrigerant gas pipe 
2 Refrigerant liquid pipe 
3 Service vlave (gas) 5/8
4 Service vlave (liquid) 3/8
5 Drain hole Connection with the provided drain plug.
