34
SAMSUNG ELECTRONICS
No. Parts Procedure Remark
3) Please remove the compressor after
loosen the compressor xed NUT 3ea.
(Using MONKEY SPANNER)
4) Please detach the two welds.
(SUCTION, DISCHARGE)
