Samsung AR12TXFCAWKXEU - Assy Pcb Inverter Db92-04838 A

63
SAMSUNG ELECTRONICS
6-4 ASSY PCB INVERTER DB92-04838A
Level Parts Code Design Loc Parts Description Spec. Quantity Unit
..1 0201-001528 COATING ADHESIVE-SIL LDC2577D,Y/GRN,175CPS 8.9 G
..1 0201-001982 ADHESIVE-SIL ADHESIVE-SIL
TSE3854DS-W,White,2.2,MIL-A-
46146B,UL94V-0
0.0051 KG
..1 0202-001463 SOLDER-WIRE SOLDER-WIRE
LFC2-W3.0,D3,99.79Sn/0.2Cu/0.01P,No
Flux
15 G
..1 0202-001608
SOLDER-WIRE
FLUX
SOLDER-WIRE FLUX
LFC7-107,D0.8,99.3Sn/0.7Cu/0.01P,Flux
3.5%
7.5 G
..1 0204-005794 SOLVENT SOLVENT S-1000,(CH3)2CHOH,100%,0.79 2.5 G
..1 0402-000324 BD151 DIODE-BRIDGE D3SB60,600V,4A,SIP-4,ST 1 PC
..1 0402-002299 BD051 DIODE-BRIDGE PB3006,600V,30A,SIP-4(2S),ST 1 PC
..1 0402-002300 D054 DIODE-RECTIFIER IDW30C65D1,600V,30A,TO-247,ST 1 PC
..1 0508-001265 Q051 TR-IGBT 600V,30A,2.3V,94W 1 PC
..1 1203-000242 REG161 IC-POSI.FIXED REG.
7812,TO-220,3P,PLASTIC,11.5/12.5V,16W,
0to+125C,0v,TP
1 PC
..1 1404-001194 PTC301 THERMISTOR-PTC
39ohm(Typ),270VAC,1.2A,RADIAL(DISC),0.
2A,11x5mm,TP
1 PC
..1 1404-001413 NTC151 THERMISTOR-NTC
18ohm,3A,3200K,19MWC,15mm,TP,17x6
mm,RADIAL(DISC)
1 PC
..1 1404-001498 PTC020 THERMISTOR-PTC
40ohm,290VAC,7A,CASE,17.7x13.5x9mm,
TR
1 PC
..1 1404-001862 NTC052 THERMISTOR-NTC
47Kohm,3975K,2MWC,TP,2.0x4.0mm,AXI
AL
1 PC
..1 1405-001239 VA001 VARISTOR
680V,560VDC,6000A,17x10mm,TP,1120V,
350pF,D14
1 PC
..1 1405-001239 VA151 VARISTOR
680V,560VDC,6000A,17x10mm,TP,1120V,
350pF,D14
1 PC
..1 1405-001438 VA002 VARISTOR
560V,450VDC,4500A,17.5x8mm,TP,920V,
600pF,D14
1 PC
..1 1405-001438 VA003 VARISTOR
560V,450VDC,4500A,17.5x8mm,TP,920V,
600pF,D14
1 PC
..1 1405-001438 VA004 VARISTOR
560V,450VDC,4500A,17.5x8mm,TP,920V,
600pF,D14
1 PC
..1 2201-002427 C904 C-CERAMIC,DISC
2.2nF,10%,2000V,Y5P,TP,12.5x5mm,7.5
mm
1 PC
..1 2201-002688 C155 C-CERAMIC,DISC
2.2nF,20%,400Vac,Y5U,TP,12.5x7mm,10
mm
1 PC
..1 2201-002688 C156 C-CERAMIC,DISC
2.2nF,20%,400Vac,Y5U,TP,12.5x7mm,10
mm
1 PC
..1 2201-002705 C002 C-CERAMIC,DISC 3.3nF,20%,400Vac,Y5U,TP,14x7mm,10mm 1 PC
..1 2201-002705 C003 C-CERAMIC,DISC 3.3nF,20%,400Vac,Y5U,TP,14x7mm,10mm 1 PC
..1 2201-002705 C004 C-CERAMIC,DISC 3.3nF,20%,400Vac,Y5U,TP,14x7mm,10mm 1 PC
..1 2201-002705 C005 C-CERAMIC,DISC 3.3nF,20%,400Vac,Y5U,TP,14x7mm,10mm 1 PC
..1 2201-002707 C056 C-CERAMIC,DISC 4.7nF,10%,2000V,Y5P,TP,16x5mm,10mm 1 PC
..1 2301-001285 C006 C-FILM,LEAD-PPF 680nF,10%,275Vac,BK,31x11x21mm 1 PC
..1 2301-001949 C001 C-FILM,LEAD 3300nF,10%,275Vac,BK,31x21x31mm 1 PC
..1 2301-002457 C308 C-FILM,LEAD-MPPF 4.7nF,20%,300V,TP,5x11x12.5mm 1 PC
..1 2301-002457 C309 C-FILM,LEAD-MPPF 4.7nF,20%,300V,TP,5x11x12.5mm 1 PC
..1 2301-002457 C310 C-FILM,LEAD-MPPF 4.7nF,20%,300V,TP,5x11x12.5mm 1 PC
