Samsung AS12A1VC Service Manual

18
4-3 PCB Box
4-3-1 PCB Box
■ Parts List
1
2-2
2-4
4
2
3
2-3
2-1
No
1
2
2-1
2-2
2-3
2-4
3
4
CODE NO
DB61-10151A
DB93-10574A
DB93-10608A
DE26-20154A
DE26-20166A
2306-000294
2301-001255
3501-001058
DE32-10037A
3601-001095
DB93-10560B
DB32-10008D
Description
CASE-CONTROL
Ass'y main PCB
Ass'y main PCB
Trans-power
Trans-power
C-film
C-film
Power-relay
Fuse
Fuse
Ass'y-display and Remocon Module
Thermistor-EVAP
Specification
-
-
AC230V DC17V 300mA
AC125V, DC17V, 300mA
CFS 99N 450VAC 155K
300VAC 4µF
DI1U DC12V
250V 3.15A
T, 125V, 3.15A
-
103AT 240/240
Q’TY
AQ09A2VA AQ12A2VC
1
1
-
-
1
-
1
1
-
1
1
1
1
-
1
1
-
1
-
1
1
-
1
1
Remark
1- 5/14/01 8:55 PM Page 18
