Samsung AS24A2RCD - Page 23

23
■
Part’s List
Q’TY
Code No.
No.
Description Specification
AS18A9(0)RCF
AS18A9(0)RCFD
AS24A1(2)RC
AS24A1(2)RCD
1
2
3
3-1
3-2
3-3
4
5
6
6-1
7
7-1
7-2
8
9
10
10-1
10-2
11
12
13
13-1
14
15
16
17
18
19
20
21
22
DB64-00127A
DB63-30150C
DB95-00287N
DB61-10164B
DB63-00436D
DB63-00435D
DB63-00091A
DB64-00130A
DB93-00311C
DB63-00115A
DB94-00099B
DB31-10153B
DB66-00104A
DB96-01125B
DB96-01125H
DB67-00058A
DB90-00884B
DB61-00601A
DB65-00039H
DB31-10151D
DB94-00040J
DB94-40003A
DB94-40007A
DB93-01985A
DB32-00027B
DB61-10163A
DB94-00107A
DB90-00434A
DB70-10663A
DB63-00227A
DB70-00115A
DB93-00861A
GRILLE AIR INLET
GUARD AIR FILTER
CLEANER FILTER ASS´Y
CASE-CLEANER FILTER
CARBON FILTER
CLEANER FILTER
COVER TERMINAL
FRONT PANEL
ASS´Y PCB DISPLAY
COVER DISPLAY
ASS´Y TRAY DRAIN
STEPPING MOTOR
BLADE-H
ASS´Y EVAP
ASS´Y EVAP
SPACER-EVAP
ASS´Y HOLDER MOTOR
HOLDER MOTOR
TERMINAL BLOCK ASS´Y
MOTOR FAN IN
ASS´Y-CROSS FAN
RUBBER BEARING
BEARING MOTOR
ASS´Y MAIN PCB
ASS´Y-THERMISTOR
CASE CONTROL
ASS´Y BACK BODY
ASS´Y HOLDER PIPE
PLATE HANGER
COVER-TERMINAL BLOCK
PLATE-KNOCKOUT
ASS´Y REMOCON
HIPS
PP
ASS’Y
PP
POLYESTER/CARBON
POLYESTER/COTTON
ABS(V0)
HIPS
ASS’Y
ABC(BLK)
ASS´Y
MP24S
ABS
PLATE1.2(5/8”)
SLIT1.5(1/2”)
PVC
ASS’Y
PP(Vo)
6P, 25A
IIC-9430SKF7A
ø95 x L
CR(BLK)
ASS’Y
PD-SH30ZC-01
103AT / DKS-103FW
PP
HIPS
ASS’Y
SGCC-M
ABS
SGCC-M
ASS’Y
1
2
1
2
1
1
1
1
1
1
1
1
1
1
-
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
2
1
1
1
1
1
1
1
1
1
-
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
AS18A9(0)RCF SM_E_15775 3/10/05 7:15 PM Page 23
