14 Slide the chassis into the cabinet.
14-1 Carefully slide the air conditioner back
into the
cabinet.
14-2 Place the bottom
gasket
between
the bottom
ofthe
chassis and the
inside bottom of the cabinet. Fold uo the ends on both
sides of the bottom
gasket
and
push
them in.
1+3 Reinstall 2 front screws on the side of unit
amono
the
removed screws
in
page
17.
15 Install the window
gasket.
Cut
the window
gasket
to the window width and stufi it between
the window
and
the
glass
to
prevent
air and insects
from
getting
into the room.
16 Reinstall the
panel
and
grille.
'1G1
Fix the
upper
front
panel.
16-2 Slide one side of the
lower
part
of the front
panel
slighfly
backward.
16-3 Slide the other
side backward.
164 Reinstall the front
grille
to the cabinet after replacing
the screw
removed
in steD 2.
17 Check
for air leaks and
seal.
>
Some
installations may
require additional sealing around
the
window and air conditioner.
18
Plug in the
power,
tum
the air conditioner on, operate
it in Cool mode
i,.
,',
...'.
.
and check for unusual vibrations-
,.
.
..
>
Affer several minutes the unit
will be blowing out cold air.
lf
the
unit
does not,
please
retum it to the dealer.
