Samsung AZ09FATEA - Page 12

Samsung Electronics 3-7
Installation and Operating Instructions
Temperature
[˚C]
THERMISTOR RESISTOR
[Kohm]
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
1.670
1.729
1.791
1.855
1.922
1.992
2.065
2.141
2.220
2.303
2.390
2.480
2.574
2.672
2.775
2.882
2.994
3.111
3.234
3.362
3.496
3.635
3.780
3.932
4.091
4.257
4.432
4.614
4.806
5.007
5.217
5.438
5.669
5.912
6.167
6.435
6.716
7.012
7.322
7.649
7.993
Temperature
[˚C]
THERMISTOR RESISTOR
[Kohm]
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
-1
-2
-3
-4
-5
-6
-7
-8
-9
-10
8.354
8.734
9.135
9.556
10.00
10.46
10.94
11.45
11.99
12.55
13.15
13.78
14.44
15.14
15.88
16.66
17.48
18.36
19.28
20.25
21.28
22.38
23.54
24.76
26.06
27.44
28.90
30.45
32.10
33.85
35.66
37.59
39.64
41.82
44.14
46.60
49.22
52.01
54.98
58.14
2. "Indoor pipe Thermistor" and "Outdoor pipe Thermistor" (SPEC : 10KD)
(J)DB98-03455A(1)-1 9/12/01 1:24 PM Page 3-7
