Exploded View and Parts List
■Part List (Type "B" )
No Description Code No. Specification
Q'TY
AZ12AADEA AZ12FADEA
1 INLET GRILLE DB64-10145A HIPS 1 -
DB64-00101A HIPS - 1
DB64-00012G HIPS - -
2 ASS'Y PANEL FRONT DB92-10319G A-TYPE 1 -
DB92-00072A F-TYPE - 1
2-1 FILTER DB63-30142C A-TYPE 1 -
DB63-00073B F-TYPE - 1
2-2 PANEL-FRONT DB64-70080A A-TYPE 1 -
DB64-00168A F-TYPE - 1
2-3 BLADE-H DB66-30169A A-TYPE 1 -
DB66-00049A F-TYPE - 1
3 EVAPORATOR DB96-01004B 2R×14S,FP1.2 1 1
4 ARM BLADE DB66-70022D PS,BLK 1 1
5 BLADE-V DB66-30170A PP,SC-97525R 1 1
6 FRAME-BLADE DB90-00510B ASS'Y 1 1
6-1 LEVER-DAMPER DB66-70024A HIPS 1 1
7 PLATE-EVAP CASING DB71-00074A SGCC-M,T0.7 1 1
8 PLATE-PARTITION DB71-00075B SGCC-M,T0.7 1 1
9 CASE-BLOWER DB61-00649A 30FO-PS 1 1
10 NUT-FRANGE DB60-30004A M6,YEL 1 1
11 BLOWER DB67-50073A ABS OD Φ180 1 1
12 MOUNTER MOTOR DB61-00650A SGCC-M,T1.0 1 1
13 MOTOR DB31-00122C YGN60-6C 1 1
14 ASS'Y CASE EVAP DB90-00511A ASS'Y,PP 1 1
15 FAN PROPELLER DB67-00139A ABS+G/F,NTR 1 1
16 NUT-FRANGE DB60-30020A M6,LEFT 1 1
17 CASE-COND DB61-00647A PP,T2 1 1
18 BASE DB90-00514B 48 FRAME 1 1
19 CONDENSER DB96-01003B 2R×14S,FP1.5 1 1
20 COMPRESSOR 48D129JU1EL 240V/50Hz 1 1
21 ASSY-4-WAY DB99-00116A ASSY 1 1
22 ASSY-CHECK V/V DB96-02100A ASSY 1 1
24 NUT-FRANGE DB60-30001A M5,YEL 1 1
25 COVER TERMINAL DB63-10026A NORYL,BLK 1 1
26 O.L.P DB47-20057U MRA12074-12007 1 1
27 GASKET DB63-20003A EPDM,T0.8 1 1
28 NUT WASHER DB60-30028A M8,ZPC 1 1
29 GROMET ISOLATOR DB73-00067A NR 35 3 3
30 ASS'Y-CABINET DB90-00364A ASS'Y,SC-94445T 1 1
31 ASS'Y-CONTROL DB93-01412B 240V/50Hz 1 1
31-1 SWITCH MEMBRANE DB34-00026B 99.1*134.5 1 1
31-2 PANEL CONTROL DB64-00259B HIPS,T2.0 1 1
31-3 ASSY MAIN PCB DB93-00407H HEAT PUMP 1 1
31-4 CASE CONTROL UP DB61-00421A SGCC-M,T0.7 1 1
31-5 SWING MOTOR DB31-00084B M2LJ49ZV32 1 1
31-6 CAPACITER(C-OIL) 2501-001236 30µF 450VAC× 1
31-7 CLIP CAPACITOR DB65-10008B SGCC-M,T0.7 1 1
31-8 POWER CORD DB39-00348A 250V,16A 1 1
31-9 CAPACITER(C-FILM) 2301-001378 3.5µF 450VAC× 1
31-10 TRANSFORMER DB26-00006E AC230V,50/60HZ 1 1
31-11 CASE CONTROL LOW DB61-00417A SGCC-M,T0.7 1 1
31-12 THERMISTOR DB32-10051E 10K/25,-,3435K 1 1
31-13 THERMISTOR COND DB32-10045G 4100,10K,25,-20~70 1 1
32 TRAY DRAIN DB63-00276A 30FOAM-PS 1 1
33 ASSY REMOCON DB93-00284L W-RAC,ARH-700 1 1
Samsung Electronics 6-4
