Samsung C27FG73FQU

27
Connection Using an DP Cable
DP IN
―
A DP cable shorter under 1.5 m in length is recommended. Using a cable longer than 1.5 m can affect the
picture quality.
Connecting to Headphones
―
Use headphones when activating sound with a HDMI-HDMI or DP cable.
―
The Interactive feature in Arena Lighting is available. This feature works in conjunction with audio input.
(C*FG70* model only)
Connecting the Power (C24FG70FQ* / C24FG73FQ*
model only)
C24FG70FQ*
2
DC 19V
HDMI IN 1
HDMI IN 2
DP IN SERVICE
4
3
1
C24FG73FQ*
2
DC 19V
HDMI IN 1
HDMI IN 2
DP IN
SERVICE
4
3
1
1
Connect the power plug to the AC/DC adapter.
2
Connect the AC/DC adapter cable to the DC 19V port on the back of the monitor.
3
Plug the AC/DC adapter into the power outlet.
4
Press the JOG button on the back of the monitor to turn it on.
―
The input voltage is switched automatically.
