10
Adjusting the Product Tilt and Height
―
The color and shape of parts may differ from what is shown. Specifications are subject to change without
notice to improve quality.
• The product tilt can be adjusted.
• When adjusting the tilt and height, hold both sides of the product and avoid using excessive force to
prevent damage.
• When adjusting the stand height, you may hear a noise. This noise is generated because the ball
inside the stand slides when the stand height is adjusted. It is a normal noise and not a product
malfunction.
C27G7*T* / C32G7*T*
-15.0˚ (±2.0˚) ~ +15.0˚ (±2.0˚)
-9.0˚ (±2.0˚) ~ +13.0˚ (±2.0˚)
0 ~ 120.0 mm (±5.0 mm)
-2.0° (±2.0°) ~ 92.0° (±2.0°)
C49G9*T*
-15.0˚ (±2.0˚) ~ +15.0˚ (±2.0˚)
-3.0˚ (±2.0˚) ~ +13.0˚ (±2.0˚)
0 ~ 120.0 mm (±5.0 mm)
