No. Parts No. Description Specification Q'ty Remarks
P 1 0502-000303 TR-POWER KSD882,NPN,1W,TO-126,TP,160-32 1 Q01
P 2 3406-001031 SWITCH-ROTARY 10V,1mA,DP24T,18.3mm 1 ECD1
P 3 3501-000265 RELAY-POWER 12V,-,16A,-,15mS,15mS 2 CONV-H,CONV-M
P 3 3501-000265 RELAY-POWER 12V,-,16A,-,15mS,15mS 2 GRILL,INRUSH
P 3 3501-000265 RELAY-POWER 12V,-,16A,-,15mS,15mS 2 MAIN,POWER
P 4 3501-000334 RELAY-REED 12V,1250VA,10A,-,10mS,5mS 1 RELAY
P 5 3711-000315 CONNECTOR-HEADER 1WALL,7P,1R,3.96mm,STRAIGHT,SN 1 CON04
P 6 3711-000607 CONNECTOR-HEADER BOX,11P,1R,2.50mm,ANGLE,SN 1 CON06
P 7 3711-000612 CONNECTOR-HEADER BOX,11P,1R,2.5mm,STRAIGHT,SN 1 CON02
P 8 3711-001343 CONNECTOR-HEADER NOWALL,1P,1R,3.4mm,STRAIGHT,AG 1 GND
P 9 DE07-10052A V.F.DISPLAY SVM-4MS13S,MWO,RE-1280 1 VFD
P10 DE09-30158A IC-MCU TMS73C91-C69416,DIP,RE-1280 1 MICOM
P11 DE13-20016A IC-VOLT REGU KA7805A,TO-220AB,1A,0/125C 1 IC04
P12 DE13-20017A IC-DRIVE KID65003AP,DIP,16P,STICK,TR-AR 1 IC02
P13 DE30-20016A BUZZER CBE2220BA,STICK 1 BUZZER
P14 DE61-90034D HOLDER-DIGITRON PP(JI350),BLK 1 -
P15 0401-001002 DIODE-SWITCHING 1N4148M,100V,200mA,DO-34,TP 7 D03,D09,D10,D11~D14
P16 0402-001103 DIODE-RECTIFIER 1T4,400V,1A,TS-1,TP 7 D01,D02,D04,D05~D08
P17 0403-000150 DIODE-ZENER 1N4743A,13V,5%,1W,DO-41,TP 1 ZD02
P18 0403-000525 DIODE-ZENER 1N4733A,5.1V,5%,1W,DO-41,TP 1 ZD01
P19 0501-000283 TR-SMALL SIGNAL KSA539,PNP,400mW,TO-92,TP,120- 2 Q09,Q10
P20 0501-000388 TR-SMALL SIGNAL KSC815,NPN,400mW,TO-92,BK,120- 2 Q04,Q05
P21 0504-001045 TR-DIGITAL KRC119M,NPN,400MW,4.7K/10K,TO-92M,TP 4 Q02,Q03,Q06,Q08
P22 0504-001046 TR-DIGITAL KRA119M,PNP,400MW,4.7K/10K,TO-92M,TP 1 Q07
P23 2001-000042 R-CARBON 1KOHM,5%,1/4W,AA,TP,2.4X6.4MM 5 R04,R05,R09,R27,R28
P24 2001-000062 R-CARBON 470OHM,5%,1/4W,AA,TP,2.4X6.4MM 3 R01,R02,R03
P25 2001-000065 R-CARBON 10KOHM,5%,1/4W,AA,TP,2.4X6.4MM 5 R06,R07,R08,R12,R14
P25 2001-000065 R-CARBON 10KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R16,R21
P26 2001-000076 R-CARBON 47KOHM,5%,1/4W,AA,TP,2.4X6.4MM 4 R33,R34,R35,R36
P27 2001-000432 R-CARBON 1MOHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R24,R25
P28 2001-000575 R-CARBON 2KOHM,5%,1/4W,AA,TP,2.4X6.4MM 2 R10,R23
P29 2001-000611 R-CARBON 3.9KOHM,5%,1/4W,AA,TP,2.4X6.4MM 5 R11,R13,R15,R17,R18
P29 2001-000611 R-CARBON 3.9KOHM,5%,1/4W,AA,TP,2.4X6.4MM 5 R20,R29,R30,R31,R32
P30 2004-000193 R-METAL 100Kohm,1%,1/4W,AA,TP,2.4x6.4m 1 R19
P31 2004-000432 R-METAL 1Kohm,1%,1/4W,AA,TP,2.4x6.4mm 1 R26
P32 2004-001118 R-METAL 5Kohm,1%,1/4W,AA,TP,2.4x6.4mm 1 R22
P33 2201-000442 C-CERAMIC,DISC 3.3nF,10%,50V,X7R,-,-,08x5.0 4 C14,C15,C16,C17
P34 2201-000817 C-CERAMIC,DISC 22pF,79.8,50V,Y5V,TP,4x4,5 2 C08,C09
P35 2202-000780 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,TP,3.5x1 5 C05,C06,C07,C12,C19
P36 2401-000030 C-AL 22uF,20%,25V,GP,TP,5x11,5 1 C18
P37 2401-000159 C-AL 1000uF,20%,25V,GP,-,13x25x7.5m 1 C03
P38 2401-000244 C-AL 100uF,20%,10V,GP,TP,6.3x7,5 1 C04
P39 2401-000466 C-AL 10uF,20%,35V,GP,TP,5x7,5 2 C10,C11
P40 2401-000598 C-AL 1uF,20%,50V,GP,TP,4x7,5 1 C13
P41 2401-001415 C-AL 470uF,20%,35V,GP,TP,10x20,5 2 C01,C02
P42 2802-000143 RESONATOR-CERAMIC 4.19MHz,0.5%,TP,10.0x5.0x7.5mm 1 XTAL
P43 3404-001022 SWITCH-TACT 15V,20mA,130°æ40gf,6x6x5mm,SPS 14 SW01~SW14
P44 3711-000881 CONNECTOR-HEADER BOX,3P,1R,2.5mm,STRAIGHT,SN 2 CON05,CON07
P45 3711-000940 CONNECTOR-HEADER BOX,4P,1R,2.5mm,STRAIGHT,SN 1 CON03
P46 3711-000999 CONNECTOR-HEADER BOX,5P,1R,2.5mm,STRAIGHT,SN 1 CON01
P47 DE13-20009A IC KA7533,DIP 1 IC03
P48 DE39-40113A WIRE HARNESS-F 110/220V,60HZ,MX200TCC,130MMX3 1 -
P49 DE39-60001A WIRE-SO COPPER PI0.6,SN,T,52MM,TAPING_WIRE 35 J01~J35
P50 DE41-10108A P.C.B-MAIN-SUB FR-1,T1.6,W197,L327,RE-1280 1 PCB
P51 DE92-90093D ASSY-HEAT SINK JVM-190K,A-TYPE 1 -
8-2 P.C.B Parts List
P.C.B Diagrams
Samsung Electronics 8-2
