Samsung CE935GR - Door Parts List; Control Parts List

Samsung Electronics 7-3
7-3 Door Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks Old Parts No.
D 1 DE64-40011A DOOR-A;RESIN-ABS(HR-0370U) T2.5 M945(IDE 1
D 2 DE64-40006A DOOR-KEY;POM(TC3005) T2.0 12GR BLK CE9 1
D 3 DE61-70032A SPRING-KEY;ES HSWR PI0.6 D5.4 L25 MW8640 1 72724-0038-00
D 4 DE67-20003D SCREEN-DOOR;PC T1.5 L317.5 W401.5 WHT(GR 1
D 5 DE92-50127A ASSY DOOR-E;COAT BLACK M97G45 1
D 6 DE64-40012A DOOR-C;RESIN-PP(TB53) T2.0 CE945GF BLA 1
D 7 DE01-00002A FILM-DOOR;PET T0.15 275 175 NTR CE945GF 1
7-4 Control Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks Old Parts No.
C 1 DE66-20006A BUTTON-PUSH;RESIN-ABS(HR-0370U) P/WHT M9 1
C 2 DE61-70076A SPRING-BUTTON;HSWR PI0.6 1 76674-239-310
C 3 DE64-10123A KNOB;ABS PURE-WHT M97G35 2
C 4 DE72-70008C CONTROL-PANEL;ABS(HR0370U) T2.5 CE935GR 1
C 5 DE45-10076A TIMER-ASSY;TMFK60MTB1 220V/240V 310-GRIL 1
C 6 3501-000309 RELAY-POWER;CHP11-A240S-250V15A 240V,375 1 A3068-0052
C 7 DE39-40333B ASSY WIRE HARNESS-B;230V50HZ CE735G/CE93 1
7-5 Body Latch Parts List
Ref. No. Parts No. Description/Specification Q'ty Remarks Old Parts No.
B 1 DE66-40001A LATCH-BODY;POM(F20-02) 40GR NTR 1
B 2 3405-000178 SWITCH-MICRO;VP-533A-OF-PS(T85) 250V,15A 2 73579-203-207
B 3 3405-000175 SWITCH-MICRO;VP-531A-OF(T85) 250V,15A,20 1 73579-203-278
B 4 DE66-90001A LEVER-SWITCH;P.O.M(F20-02) 2 6 NTR 2ND-W 1
Exploded Views and Parts List
