MODEL
INDOOR UNIT CH140EAMC CH105EAMC CH070EAMC
OUTDOOR UNIT UH140GAMC UH105GAMC UH070EAMC
Capacity
Cooling
BTU/h 48,000 34,120 23,88 5
W 14,000 10,000 7,000
Heating
BTU/h 52,800 36,510 24,567
W 15,400 10,700 7,200
Power Supply
Φ/V/Hz
3Φ/380~415 V/50 Hz 3Φ/380~415 V/50 Hz 220-240V~,50Hz
Power
Input
Cooling W 5,300 3,560 2,400
Heating W 5,900 3,600 2,350
Running
Current
Cooling A 9.20 6.20 11.0
Heating A 10.00 6.30 11.0
Max current / power 11.5 A/6.5 kW 8.10A/4.39 kW 13.5 A/3.05kW
Indoor
Unit
Fan Speed
Hi r.p.m 600 ±20 540/520 ±20 460/440 ±20
Mid r.p.m 560 ±20 500/480 ±20 440/420 ±20
Low r.p.m 520 ±20 460/440 ±20 420/400 ±20
Air Flow Rate
Hi m
3
/min 29 24.5 18.5
Mid m
3
/min 27 22.5 17.0
Low m
3
/min 25 20.5 16.0
Noise Level( Cooling/ Heating ) dB(A) 49/50 47/48 43/44
Heat Exchanger
Type
Slit , Φ 7 , 2R X13S, FP1.4 Slit , Φ 7 , 2R X12S, FP1.5 Slit , Φ 7 , 2R X8S, FP1.6 6
Row sxStagesxFin pitch 2*13*1.4 2*12*1.5 2*8*1.6
Fan Type Turbo Turbo Turbo
Dimensions
H mm 298 298 218
W mm 840 840 840
D mm 840 840 840
Weight Net/Gross kg 29/35 28/34 25/ 31
Outdoor
Unit
Fan Speed
Hi r.p.m 1020 ±50 108 0±50 900 ±50
Low r.p.m 600±50 750 ±50 870 ±50
Noise Level( Cooling/ Heating ) dB(A) 67/68 65/66 60/61
Fan Type Propeller Propeller Propeller
Compressor
Type Scroll , 3phase Scroll , 3phase Rotary 1
Model BN62YFAMT AN42YBFMT G5A240JUAEM
Output Btu/h 56,640 37,200 24,100
Protection External External Internal
Refrigerant
Type R410A R410A R410A
Charge g 3,300(116.4oz) 2,750 (97.0oz) 1,700(60oz)
Adding
Charge
g/m 70 70 40
Control Expansion Valve Expansion Valve Expansion Valve
Heat Exchanger
Type Slit , Φ 7 Wide fin Slit , Φ 7 norm al fin Slit , Φ7 norm al fin
Row sxStagesxFin pitch 2* 52*1.4 2*42*1.3 2*28*1.4
Dimensions
H mm 1128 931 648
W mm 932 880 880
D mm 375 320 310
Weight Net/Gross kg 121/1 36 87/92 60/67
Piping
Pipe O.D Size
Liquid mm(inch) 19.05 (3/4”) 19.05 (3/4”) 9.52(3/8”)
Gas mm(inch) 9.52(3/8”) 9.52(3/8”) 15.88 (5/8”)
Connection Method Flare Flare Flare
Between
Height m Max. 30 Max. 30 Max. 15
Pipe Leng th m Max. 50 Max. 50 Max. 30
CH052EAMC
UH052EAM C
18,426
5,400
20,473
6,000
220-240V~,50Hz
1,950
1,900
8.5
8.6
11.8A/2.53 kW
400/380 ±20
380/360 ±20
360/340 ±20
14.0
13.0
12.0
43/44
Slit , Φ 7 , 2R X8S, FP1.
2*8*1.6
Turbo
218
840
840
25/31
940 ±50
900 ±50
59/60
Propeller
Rotary 1
G8D190JUAEH
19,995
Internal
R410A
1,500(53oz)
25
Expansion Valve
Slit , Φ7 norm al fin
2*28*1.4
648
880
310
59/66
6.35 (1/4 ”)
12.7 0(1/2 ”)
Flare
Max. 15
Max. 30
2-2
CH094EAMC
UH0
94EAM1
C
30,708
9,000
32,414
9,500
220-240V~,50Hz
3,400
3,500
15.5
16.0
11.8A/2.53 kW
460/440 ±20
440/420 ±20
420/400 ±20
18.5
17.0
16.0
43/44
2*8*1.6
Turbo
218
840
840
25/31
980 ±50
500 ±50
63/64
Propeller
Rotary 1
NN40VAAMT
10,200
Internal
R410A
1,800(63.5oz)
40
Expansion Valve
Louver,Φ7 normal fin
2*36*1.5
798
880
310
74/82
9.52 (3/8 ”)
15.88 (5/8 ” )
Flare
Max. 15
Max. 30
Slit,Φ7,2RX8S,FP1.6
