Samsung DBJ - Page 31

31
 

5
16
9
-P2-
1
2
3
-P1-
-P1- -P1- -P2- -P2-
Male type 

Gnd
3
2
5
----------
----------
----------
1
2
3


Gnd
STEREO
PLUG
(3.5ø)
LAN Cable
 Pin assignment
1 2 3 4 5 6 7 8
Pin No Standard Color Signal
1  TX+
2 Orange TX-
3  RX+
4 Blue NC
5  NC
6 Green RX-
7  NC
8 Brown NC
