Loc. No. Code No. Description Specification Remarks
R518 2001-001031 R-CARBON 91KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R519 2001-000356 R-CARBON 150KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R520 2001-000241 R-CARBON 1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R520 2001-000472 R-CARBON 2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 15”
R521 2008-001085 R-FUSIBLE 4.7KOHM,5%,1/4W,AA,TP,2.4X6MM
R524 2001-000660 R-CARBON 33KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R525 2001-000273 R-CARBON 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R526 2001-000273 R-CARBON 100KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R526 2001-000908 R-CARBON 62KOHM,5%,1/8W,AA,TP,1.8X3.2MM 17”
R527 2001-000864 R-CARBON 56KOHM,5%,1/8W,AA,TP,1.8X3.2MM 17”
R527 2001-000563 R-CARBON 27KOHM,5%,1/8W,AA,TP,1.8X3.2MM 15”
R527 2001-000837 R-CARBON 62KOHM,5%,1/8W,AA,TP,1.8X3.2MM TSB, PHS
R527 2001-000908 R-CARBON 51KOHM,5%,1/8W,AA,TP,1.8X3.2MM SDD
R528 2001-000262 R-CARBON 1.8MOHM,5%,1/8W,AA,TP,1.8X3.2MM
R529 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R551 2001-000530 R-CARBON 240KOHM,5%,1/4W,AA,TP,2.4X6.4MM 17”
R552 2001-000537 R-CARBON 24KOHM,5%,1/4W,AA,TP,2.4X6.4MM 17”
R553 2001-001129 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6 17”
R554 2001-001110 R-CARBON(S) 240KOHM,5%,1/2W,AA,TP,2.4X6 17”
R555 2001-000042 R-CARBON 1KOHM,5%,1/4W,AA,TP,2.4X6.4MM 17”
R556 2001-000890 R-CARBON 6.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM 17”
R600 2001-001129 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6
R601 2001-001129 R-CARBON(S) 330KOHM,5%,1/2W,AA,TP,2.4X6
R602 2001-000023 R-CARBON 47OHM,5%,1/4W,AA,TP,2.4X6.4MM
R603 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R604 2001-000857 R-CARBON 560OHM,5%,1/8W,AA,TP,1.8X3.2MM
R605 2001-000734 R-CARBON 4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R606 2003-000225 R-METALOXIDE 22Kohm,5%,1W,AA,TP,4.3x12m
R607 2003-000225 R-METALOXIDE 22Kohm,5%,1W,AA,TP,4.3x12m
R608 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R609 2001-000114 R-CARBON(S) 180KOHM,5%,1/2W,AA,TP,2.4X6
R610 2001-000114 R-CARBON(S) 180KOHM,5%,1/2W,AA,TP,2.4X6
R611 2001-001079 R-CARBON(S) 15OHM,5%,1/2W,AA,TP,2.4X6.4M
R612 2003-000738 R-METALOXIDE(S) 56Kohm,5%,2W,AA,TP,4x12m
R614 2001-001107 R-CARBON(S) 220ohm,5%,1/2W,AA,TP,2.4x6.4
R615 2001-001088 R-CARBON(S) 1KOHM,5%,1/2W,AA,TP,2.4X6.4M
R617 2001-001037 R-CARBON(S) 0.39OHM,5%,1/2W,AA,TP,2.4X6. SDD, TSB
R617 2001-001038 R-CARBON(S) 0.56OHM,5%,1/2W,AA,TP,2.4X6 PHS
R618 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R619 2003-000471 R-METALOXIDE(S) 10ohm,5%,2W,AA,TP,4x12mm
R620 2001-000354 R-CARBON 150KOHM,5%,1/4W,AA,TP,2.4X6.4MM
R621 2001-000989 R-CARBON 820KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R622 2001-000211 R-CARBON 1OHM,5%,1/4W,AA,TP,2.4X6.4MM
R625 2001-000786 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R630 2001-000786 R-CARBON 47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R631 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R632 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
!
!
!
7 Electrical Parts List
DP15H*/DP17L* 7-9
