Samsung DP15HS - Page 45

R633 2001-000211 R-CARBON 1OHM,5%,1/4W,AA,TP,2.4X6.4MM
RL601 3501-001111 RELAY-POWER 12Vdc,250mW,5A,1FormA,15mS,5
SK501 4715-000001 SURGEABSORBER 1KV,+50-10%,
SW201 3404-000244 SWITCH-TACT 15V,20mA,90-170gf,7.5x7mm,SP
SW202 3404-000244 SWITCH-TACT 15V,20mA,90-170gf,7.5x7mm,SP
SW203 3404-000244 SWITCH-TACT 15V,20mA,90-170gf,7.5x7mm,SP
SW204 3404-000244 SWITCH-TACT 15V,20mA,90-170gf,7.5x7mm,SP
SW401 3406-000002 SWITCH-ROTARY 36Vdc,200mA,SP3T
SW601 3403-001050 SWITCH-PUSH 30V,0.3A,SPDT,ON-OFF,PCBORD
T401 BH26-00027A TRANS-HOR.DRIVE 35.0MH,-,EI1916,PL-3
T402 BH26-00028A TRANS-H.LINEARITY 5.2UH,6P,DR1425(C:5.0) 17”
T402 BH26-00029A TRANS-H.LINEARITY 6.5UH,-,DR1425(C:5.0), 15”
T501 BH26-00035A TRANS-FBT 1.0MH,13P,FUR3658,HV45,FM1 17”
T501 BH26-00025A TRANS-FBT 1.0MH,13P,3763SU,SM9C,FQA- 15”
T502 BH26-00022A TRANS-FOCUS 3.0MH,6P,EI2218,SB-5S,3.0MH 17”
T502 BH26-00023A TRANS-FOCUS 5.0MH,6P,EI2218,SB-5S,5.0MH 15”
T601 BH26-00033A TRANS-SWITCHING 390UH,16P,EER3538,PL3,P 17”
T601 BH26-00032A TRANS-SWITCHING 390UH/83UH,16P,EER3538S 15”
T602 BH26-30302S TRANS-SYNC. 3-1(250UH),SB-5S,UU1116
TH601 1404-000002 THERMISTOR-PTC 9ohm,20%,TR,RECT
TH602 1404-001020 THERMISTOR-NTC 8ohm,15%,17mW/C,BK
TP501 4715-000001 SURGEABSORBER 1KV,+50-10%
X201 2801-000005 CRYSTAL-UNIT 8MHz,50ppm,28-AAM,S,35ohm,T
ZD201 0403-000355 DIODE-ZENER UZ5.1BSB,5.1V,4.97-5.18V,500
ZD202 0403-000355 DIODE-ZENER UZ5.1BSB,5.1V,4.97-5.18V,500
ZD203 0403-000355 DIODE-ZENER UZ5.1BSB,5.1V,4.97-5.18V,500
ZD204 0403-000355 DIODE-ZENER UZ5.1BSB,5.1V,4.97-5.18V,500
ZD205 0403-000361 DIODE-ZENER UZ6.2BSB,6.2V,5.99-6.24V,500
ZD502 0403-001068 DIODE-ZENER UZ4.7BSA,4.7V,4.47-4.65V,500
ZD601 0403-000361 DIODE-ZENER UZ6.2BSB,6.2V,5.99-6.24V,500
!
!
!
!
!
!
!
!
!
!
!
7 Electrical Parts List
7-10 DP15H*/DP17L*
Loc. No. Code No. Description Specification Remarks
