Samsung DP15HS - Page 46

Loc. No. Code No. Description Specification Remarks
BD102 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500
BD103 3301-000011 CORE-FERRITE BEAD AA,3.5x1.0x5.7mm,1500
C101 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
C102 2401-001334 C-AL 470nF,20%,50V,GP,TP,5x11,2.5
C103 2401-000037 C-AL 470uF,20%,16V,GP,TP,8x11.5,5
C104 2202-002008 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V
C105 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
C106 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
C107 2401-000010 C-AL 220uF,20%,16V,GP,6.3x11mm,2
C108 2401-001459 C-AL 47uF,20%,100V,GP,TP,10x16.5,5
C109 2202-002008 C-CERAMIC,MLC-AXIAL 10nF,+80-20%,50V,Y5V
C110 2401-000025 C-AL 100uF,20%,16V,GP,TP,6.3x11,5
C111 2401-000031 C-AL 47uF,20%,16V,GP,TP,5x11,5
C112 2401-000050 C-AL 10uF,20%,16V,GP,TP,5x11,2.5
C113 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
C114 2301-000231 C-FILM,PEF 3.3nF,5%,100V,TP,5.8x12.5mm,5
C116 2301-000188 C-FILM,PEF 1nF,5%,100V,TP,10.5x12.5x6.5
C117 2301-000188 C-FILM,PEF 1nF,5%,100V,TP,10.5x12.5x6.5
C118 2201-000471 C-CERAMIC,DISC .33NF,10%,50V,Y5P,TP,4X3M
C119 2201-000291 C-CERAMIC,DISC 1nF,10%,500V,Y5P,TP,8.5x5
C120 2201-000285 C-CERAMIC,DISC 1nF,10%,1KV,Y5P,TP,10x5,5
C121 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm
C123 2301-000148 C-FILM,PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm
C124 2301-000148 C-FILM,PEF 10nF,5%,100V,TP,7x3.2x7mm,5mm
C125 2401-000010 C-AL 220uF,20%,16V,GP,6.3x11mm,2
CB01 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CB02 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CB04 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm
CB05 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm
CB06 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CG01 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CG02 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CG03 2201-000483 C-CERAMIC,DISC 33pF,5%,50V,CH,TP,5x3,5
CG04 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm
CG05 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm
CG06 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CN101 3711-004228 CONNECTOR-HEADER BOX,6P,1R,2MM,ANGLE,SN
CN102 BH39-00015A CBF-HARNESS 13P/14P,200MM,WHT/BLK/RED/BL
CR01 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CR02 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
CR04 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm
CR05 2301-000010 C-FILM,PEF 100nF,5%,100V,TP,11.5x12.5mm
CR06 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5
D101 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
D102 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DB01 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DB02 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
7 Electrical Parts List
DP15H*/DP17L* 7-11
7-2 Video PCB Parts
