Samsung DP15HS - Page 47

DB03 0401-000004 DIODE-SWITCHING 1SS244,250V,200mA,DO-34
DB04 0401-000004 DIODE-SWITCHING 1SS244,250V,200mA,DO-34
DB05 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DG01 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DG02 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DG03 0401-000004 DIODE-SWITCHING 1SS244,250V,200mA,DO-34
DG04 0401-000004 DIODE-SWITCHING 1SS244,250V,200mA,DO-34
DG05 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DR01 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DR02 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
DR03 0401-000004 DIODE-SWITCHING 1SS244,250V,200mA,DO-34
DR04 0401-000004 DIODE-SWITCHING 1SS244,250V,200mA,DO-34
DR05 0401-000005 DIODE-SWITCHING 1N4148,75V,200MA,DO-35,T
HS103 BH99-00004B ASSY,HEAT/SINK H/S VIDEO,SCREW+NUT,LM243
IC101 1201-001332 IC-VIDEO AMP 2506,DIP,28P,600MIL,SINGLE
IC103 BH13-00003A IC-HYBRID LM2437,TO-220,9P,CRT DRIVER
IC104 1204-001529 IC-OSD PROCESSOR KS2501-09,DIP,24P,300MI
LB01 2701-000190 INDUCTOR-AXIAL 470nH,20%,4x9.8mm
LG01 2701-000190 INDUCTOR-AXIAL 470nH,20%,4x9.8mm
LJP1 BH39-40306D CBF-HARNESS 80MM,BLK,1015,AWG22
LR01 2701-000190 INDUCTOR-AXIAL 470nH,20%,4x9.8mm
Q101 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,T
Q102 0501-000122 TR-SMALL SIGNAL 2N3904,NPN,625mW,TO-92,T
QB01 0501-000140 TR-SMALL SIGNAL 2N5551,NPN,625mW,TO-92
QB02 0501-000138 TR-SMALL SIGNAL 2N5401,PNP,625mW,TO-92,T
QG01 0501-000140 TR-SMALL SIGNAL 2N5551,NPN,625mW,TO-92
QG02 0501-000138 TR-SMALL SIGNAL 2N5401,PNP,625mW,TO-92,T
QR01 0501-000140 TR-SMALL SIGNAL 2N5551,NPN,625mW,TO-92
QR02 0501-000138 TR-SMALL SIGNAL 2N5401,PNP,625mW,TO-92,T
R101 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R102 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R103 2001-001138 R-CARBON(S) 390OHM,5%,1/2W,AA,TP,2.4X6.4
R104 2001-001138 R-CARBON(S) 390OHM,5%,1/2W,AA,TP,2.4X6.4
R105 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R106 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R107 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R108 2001-000857 R-CARBON 560OHM,5%,1/8W,AA,TP,1.8X3.2MM
R109 2001-000857 R-CARBON 560OHM,5%,1/8W,AA,TP,1.8X3.2MM
R110 2001-000812 R-CARBON 5.6KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R111 2001-000563 R-CARBON 27KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R113 2001-000429 R-CARBON 1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R114 2001-000780 R-CARBON 470OHM,5%,1/8W,AA,TP,1.8X3.2MM
R115 2001-000001 R-CARBON 2Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R116 2001-000290 R-CARBON 10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R117 2001-000591 R-CARBON 3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
R118 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM
R119 2001-000281 R-CARBON 100OHM,5%,1/8W,AA,TP,1.8X3.2MM
7 Electrical Parts List
7-12 DP15H*/DP17L*
Loc. No. Code No. Description Specification Remarks
