Samsung DV456 Series - User Manual

Other manuals for Samsung DV456 Series

Technical Information24 pages

Questions and Answers

R
Reginald MendezAug 17, 2025
What to do if my Samsung Dryer will not start?
- H
  Hannah McintyreAug 17, 2025
  If your Samsung Dryer won't start, ensure all wires are correctly connected, and the dryer is plugged in. Check for blown fuses or tripped circuit breakers. Verify the door switch is functional and the door is closed, looking for error code 3. Confirm the Start/Pause rotary selector dial and the control board are operational. Also, check if the belt is off or broken, activating the Belt Cut-off Switch, and ensure the drive motor is functional. Finally, check the motor winding resistance: it should be 2.88 ohms between pin #3 and 4, and 3.5 ohms between pin #4 and 5.
J
Jennifer GriffithAug 19, 2025
Why is my Samsung DV456 Dryer so noisy and vibrating?
- T
  Terri DeanAug 19, 2025
  A noisy and vibrating Samsung dryer can be caused by several issues. A thumping sound may indicate a loose tumbler baffle, worn or misaligned rear tumbler rollers, an out-of-round tumbler, or a high weld seam on the tumbler. Ticking sounds can be due to a loose wire harness or an object caught in the blower wheel area. Scraping sounds may be caused by a front or rear bulkhead felt seal out of position or worn tumbler front bearings. A roaring sound could mean the blower wheel is rubbing on the blower housing or the motor bearings are bad. A popping or squealing sound could indicate a sticky or frayed belt.
J
Jennifer JacksonAug 22, 2025
How to fix a Samsung DV456 that runs but won't heat?
- T
  traceystoneAug 22, 2025
  If your Samsung dryer runs but doesn't heat, check for an open heating element, a hi-limit that trips easily or is open, or a regulating thermostat that trips easily or is open. Also, inspect the membrane switch for being open and check the thermistor.
S
Sherri SmallAug 25, 2025
Why are my clothes wrinkled and taking too long to dry in my Samsung DV456 Dryer?
- M
  Madeline BrowningAug 26, 2025
  Clothes may be wrinkled, have a rough texture, or take too long to dry in your Samsung dryer due to several reasons. Ensure the lint filter is clean and there are no restrictions in the exhaust. Check that the outside exhaust hood damper door isn't stuck closed and the exhaust isn't too long, doesn't have too many elbows, or uses flex ductwork. Make sure the dryer has sufficient intake air and the tumbler speed is correct, with no belt slippage. Also, check for a bound blower impeller and remove any foreign material. Avoid overloading the dryer, check clothing labels for fabric content and the selected cycle, and ensure clothes aren't too wet from the washer.
M
Maria ConnerAug 28, 2025
Why does my Samsung DV456 Dryer run for a few minutes and then stop?
- A
  Arthur OrtizAug 28, 2025
  Your Samsung dryer might run for a few minutes and then stop due to lint buildup around the drive motor, low voltage, a blocked blower impeller in the blower housing, or the drive motor's start switch contacts being stuck closed.
T
Taylor BlackAug 30, 2025
What to do when the motor runs but the tumbler won't turn on my Samsung Dryer?
- C
  Carol HoltAug 30, 2025
  If the motor runs but the tumbler won't turn on your Samsung dryer, the belt might be off, broken, or damaged. Another potential cause could be a weak or stretched idler tension spring. Also, the idler pulley might be jammed or stuck.
G
gregory54Sep 2, 2025
What to do if my Samsung DV456 Dryer keeps blowing fuses?
- A
  anunezSep 2, 2025
  If your Samsung dryer keeps blowing fuses or tripping the circuit breaker, check the belt connection, the motor winding continuity (rotor, stator, generator), and the motor protector's condition. If these components are not the cause, the PCB assembly may be faulty and require replacement.
J
John MillerSep 5, 2025
Why does my gas Samsung DV456 Dryer blow fuses?
- J
  Justin DavisSep 5, 2025
  If your gas Samsung dryer is blowing fuses, it could be due to several reasons. During ignition, the dryer draws a certain amperage; if it's drawing more than usual with the burner ON, the issue might be with the house wiring, fuse box, or circuit breaker. Also, check for a loose igniter harness shorted to the base, incorrect wiring or a wire shorted to ground, or a drive motor winding shorting to ground.
M
munozmaxwellSep 7, 2025
Why does the flame go out after ignition in my Samsung gas Dryer?
- J
  Jacob MirandaSep 7, 2025
  If the gas ignites but the flame goes out in your Samsung gas dryer, it could be due to radiant sensor contacts opening prematurely, a weak gas valve coil that opens when stressed by higher temperatures, a weak hi-limit, poor venting, or bad drum seals.
A
Andrew MendezSep 12, 2025
What causes the igniter to not glow in my Samsung DV456?
- W
  William BishopSep 12, 2025
  If the igniter in your Samsung dryer doesn't glow, it could be due to an open flame sensor or an open igniter. Other potential causes include a shorted booster coil, open wiring, a bad motor switch (neutral supply), or no power from the control (L1 supply).

Summary

Dryer Features

Extra Large Capacity

Highlights the large drum size for drying extra-large loads efficiently.

Sanitize Cycle

Explains the cycle that uses high heat to eliminate 99.9% of bacteria.

Drying Cycles and Fuzzy Logic

Details various automatic drying cycles and the fuzzy logic control.

Time and Energy Saving

Highlights features that reduce drying time and conserve energy.

Easy Reversible Door

Explains the ability to change the door opening direction for convenience.

Smart Care Functionality

Describes using a smartphone to diagnose and troubleshoot dryer issues.

Safety Instructions

Important Safety Symbols and Precautions

Explains the meaning of warning symbols and essential safety guidelines.

Installing Your Dryer

Unpacking and Requirements

Covers unpacking the dryer and essential installation prerequisites.

Ducting Requirements

Details the specifications for the dryer's exhaust duct system.

Gas Requirements

Outlines necessary gas supply and connection specifications.

Electrical Requirements

Specifies electrical service, grounding, and connection needs.

General Installation Procedure

Provides step-by-step instructions for installing the dryer.

Leveling the Dryer

Explains how to ensure the dryer is level for optimal performance.

Operating Your Dryer

Control Panel Overview

Introduces the dryer's control panel and its main components.

Digital Display and Controls

Explains the function of the digital display and various control buttons.

Cycle Options and Settings

Details the available drying cycles, levels, and temperature settings.

My Cycle and Smart Care

Describes saving custom cycles and using smartphone diagnostics.

Loading and Starting the Dryer

Guides on properly loading laundry and starting a drying cycle.

Care and Cleaning

Control Panel and Exterior Care

Provides instructions for cleaning the dryer's exterior and control panel.

Tumbler Cleaning

Advises on removing stains from the dryer's interior drum.

Dryer Exhaust System Maintenance

Recommends periodic cleaning of the exhaust system for performance.

Special Laundry Tips

Drying Specific Fabric Types

Offers guidance for drying various materials like blankets and synthetics.

Items to Avoid in the Dryer

Lists materials and items that should not be placed in the dryer.

Troubleshooting

Common Dryer Problems

Lists typical issues and their solutions, like not running or heating.

Error Codes and Information

Explains displayed error codes and troubleshooting steps.

Appendix

Fabric Care Chart

Provides a guide to garment care symbols for washing, drying, and ironing.

Product Specifications

Lists technical details including dimensions, weight, and heater rating.

Cycle Chart

Details recommended items, load sizes, and functions for each dryer cycle.

Warranty (U.S.A)

Limited Warranty Terms

Outlines the warranty period, coverage, and service procedures for the U.S.

Warranty (Canada)

Limited Warranty Terms

Outlines the warranty period, coverage, and service procedures for Canada.

Samsung DV456 Series Specifications

General

Brand	Samsung
Model	DV456 Series
Ventless	No
Dryer Venting	Rear
Wrinkle Prevention Option	Yes
Moisture Sensor	Yes
Width	27 inches
Type	Electric Dryer
Drying Cycles	Multiple
Dimensions	27" (Width)
Steam	Yes
Color	White
