Installation
Installation
English38
7. Re-insert the two screws that held
the lever holder into the same screw
holes, and then tighten.
8. Remove the single screw from the
back of the door hinge.
NOTE
This is the screw that supports the
door against the frame so you can
unscrew or screw in the hinge without
needing to support the door yourself.
9. Insert the screw you just removed into
the other screw hole on the back of
the door hinge, and then tighten.
10. Place the door on the other side, and
then reattach it to the dryer.
NOTE
Insert the head of the screw on the
back of the hinge into the hole above
the cut out in the frame, and then slide
the door hinge down until it stops.
Make sure the protrusion on the back
of the hinge is pressed into the cut out
before you tighten the hinge screws.
