Samsung DV45K6500EV - Door Reversal

Installation
English 37
Door reversal
Type 1
1. Unplug the power cord.
2. Remove two door hinge screws.
3. Lift the door and remove it.
NOTE
There is a screw on the back side of
the hinge that will support the door as
you unscrew the hinge screws.
4. Remove the two screws that are
above and below the cut-out in the
frame front.
5. Remove the two screws above and
below the lever holder on the opposite
side of the door opening.
6. Remove the two screws that hold the
lever holder in place, and then remove
the lever holder.
