Samsung DVM S VRF - Page 99

99
4. Dimensional Drawing
Outdoor unit
• AM140KXVGGH/EU, AM160KXVGGH/EU, AM180KXVGGH/EU, AM200KXVGGH/EU, AM220KXVGGH/EU, AM140KXVAGH/EU,
AM160KXVAGH/EU, AM180KXVAGH/EU, AM200KXVAGH/EU, AM220KXVAGH/EU
250
[9 3/4”]
45
[1 3/4”]
89
[3 1/2”]
90
[3 1/2”]
1295
[4’ - 3”]
1069
[3’ - 6”]
74
[3”]
119
[4 3/4”]
202
[8”]
241
[9 1/2”]
1695
[5'-6 3/4"]
120
[4 3/4”]
118
[4 3/4”]
344
[1'-1 1/2"]
486
[1'-7 1/4"]
761
[2’ - 6”]
1150
[3’ - 9 1/4 ”]
65
[2 1/2”]
492
[2’-6”]
65
[2 1/2”]
47
[1 3/4”]
107
[4 1/4”]
95
[3 3/4”]
55
[2 1/4”]
40
[1 1/2”]
179
[7”]
115
[4 1/2”]
4-20 x 12 SLOT HOLE
Foundation bolt holes
Pitch of foundation bolt holes
Pitch of foundation bolt holes
625
[2’ -1/2”]
75
[3”]
87
[3 1/2”]
55
[2 1/4”]
616
[2’-1/4”]
65
[2 1/2”]
107
[4 1/4”]
803
[2’-7 1/2”]
765
[2'-6"]
Units : mm [inches]
NO Table of descriptions NO Table of descriptions
1 Gas Ref. pipe See note 4. 5 Power wiring conduit Φ22
2 Liquid Ref. pipe See note 4. 6 Communication wiring conduit Φ44
3 Power wiring conduit Φ34 7 Knock-out Hole for Ref. Piping (bottom)
4 Communication wiring conduit Φ44 8 Knock-out Hole for Ref. Piping (front)
