5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4 C125 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 18 SC
....4 X202 2801-003667
CRYSTAL-SMD;14.31818MHz,30ppm,28-
AAN,16p
1 SA
....4 L2011 3301-001145
BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82o
hm
4 SNA
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 2 SNA
....4 AC510 3708-001150
CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-
A,SN,Y
1 SA
....4 HB01A 3711-005743
HEADER-BOARD TO
CABLE;BOX,5P,1R,1.25mm,A
1 SA
....4 KAR11 2007-000124 R-CHIP;2.2Kohm,5%,1/10W,TP,1608 1 SNA
....4 C3 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 SNA
....4 BN97-03976J ASSY MICOM;B2340,STZ,BN94-03250J 1 SNA
.....5 IC115 1107-001580 IC-FLASH MEMORY;MX25L4005,4Mbit,512Kx8,S 1 SNA
....4 BN41-01311C PCB MAIN;PLUM B2330,CEM-3,2,MP1.0,1.6,91 1 SNA
..2 M0214 BN96-02854Y ASSY CABLE P-FLAT;Mckinley,Flat cable,17 1 SA
..2 M0006 BN96-12459B
ASSY SHIELD P-COVER;PLUM
23,SECC,T0.8,DU
1 SNA
...3 BN61-05973A STUD-PEM;PLUM23'',M4,D8,L20 2 SNA
...3 M0107 BN63-06316B SHIELD-COVER;PLUM 23,SECC,T0.8,DUAL 1 SNA
...3 M0131 BN63-00049A GASKET;RB17AS,Conductive Fabric,1.5MM,10 1 SNA
...3 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 1 SNA
..2 T0081 6001-002408
SCREW-MACHINE;BH,+,WT,M4,L12,ZPC(WHT
),SW
2 SA
..2 M0081 6003-000264
SCREW-TAPTYPE;PWH,+,-
,B,M3,L6,ZPC(WHT),S
2 SA
0.1 BN91-05280A ASSY SHIELD;E2320X 1 SNA
..2 CIS1 BN74-00021A TAPE-FILAMENT;Filament tape,clear,#8915, 0.3 SNA
0.1 BN92-05486D ASSY LABEL;Cobalt, BLACK 1 SNA
..2 CCM1 BN68-01570A LABEL RATING;ALL,SS,PE,T0.05,90,45,Dark 1 SNA
0.1 BN92-05547X ASSY P/MATERIAL;S23S1,LS23CLZSB/EN 1 SNA
..2 T0214 0203-001595 TAPE-OPP MASKING;OPP-2,0.075,75,800M,CLR 1.54 SNA
..2 6902-000061 BAG AIR;LDPE,T0.2,W500,L1000,TRP,370.000 1 SNA
..2 6902-000379 BAG AIR;LDPE,T0.2,W1000,L1800,TRP,1260.0 1 SNA
..2 T0524 6902-000520
BAG PE;HDPE/NITRON,T0.015/
T0.5(DOUBLE),W
1 SNA
..2 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 2.47 SNA
..2 6902-000609 BAG ROLL;LDPE,T0.05,W2400,L1000,TRP,30.0 0.02 SNA
..2 AA69-03810M PAD-PLATE;CB,SW,1240,800 1 SNA
..2 T0527 BH68-40364A
LABEL-SUMMARY;G52,G72,ART,100G,WHT,BL
K,W
1 SNA
..2 BH69-00457C
PACKING INNER-
00,PAD;COMM,OTHER,T3.0,880
1 SNA
..2 T0527 BN68-00129A LABEL SHIPPING-00;LABEL SHIPPING,ART-PAP 1 SNA
..2 BN69-00391Y PAD-ANGLE;CB,T5,W2100,L50,YEL,403g 1 SNA
..2 BN69-03507F
PALLET-WOOD;F2380,WOOD-
OTH,W1265,D835,H1
1 SNA
..2 BN69-04627A CUSHION-SET;COBALT23",SIMPLE,EPS,T0.018, 1 SNA
0.1 BN92-05761V ASSY BOX;LS23CLZSB/XF 1 SNA
..2 T0077 BH68-00329D LABEL BAR CODE-02;NO CE,NO WT`Y,MPRII,LA 1 SNA
..2 BN68-02258M
LABEL-STICKER
HIC;MODEL9,CHINA,MOJO,80G,
1 SNA
..2 BN69-04816A BOX-02,SET;Cobalt23"(SIMPLE),PAPER,SW,A1 1 SNA
