5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..2 BH68-00659H
LABEL BOX-00;ALL MODEL,MOJO
90G,90,95,WH
1 SNA
0.1 ACCE1 BN92-05913M ASSY ACCESSORY;LS22CLZSB/XF 1 SNA
..2 EC29 BN39-00244H CBF SIGNAL-D-SUB TO D-SUB;D-sub cable,15 1 SA
..2 SB01A BN96-12853A
ASSY STAND
P-BODY;COBALT,HIPS,BK23,ETCH
1 SA
...3 W392 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 SA
...3 T0524 6902-000023 BAG PE;LDPE,T0.08,W150,L120,TRP,1.650g 1 SNA
...3 BN61-06067A STAND-BAR;COBALT 21.5,HIPS,BK23 1 SNA
....4 BN61-06068A STAND-BAR IN;COBALT,HIPS,BK23,IN 1 SNA
...3 BN61-06334A BRACKET-PLATE;COBALT,SECC,1.0,SIMPLE 1 SNA
...3 BN68-02822J LABEL-STICKER;W/W,ART PAPER,T0.05,50,10, 1 SNA
..2 SB04A BN96-12977A ASSY STAND P-BASE;COBALT ,19N,21.5~23,HI 1 SA
...3 M0081 6003-001001
SCREW-TAPTYPE;FH,+,B,M3,L8,ZPC(BLK),SW
RC
4 SNA
...3 T0524 6902-000109 BAG PE;HDPE,T0.015,W350,L430,TRP,28,2,4. 1 SNA
...3 CIS4 BN61-01717A HOLDER-STAND;BIZET,NI PLT,CH,+,M4,L11(5) 1 SNA
...3 BN61-05087A
BRACKET-STAND BOTTOM;ECOFIT 23",SECC
T0.
1 SNA
...3 BN63-06779A
COVER-STAND BASE;COBALT
19N,21.5~24,HIPS
1 SNA
...3 AR011 BN73-00077A
RUBBER FOOT;MATISSE,BUMPON,#13.5,T2.0
,60
6 SNA
...3 BN68-02691A MANUAL FLYER-STAND;COBALT,Mojo 80g,148,2 1 SNA
...3 BN68-02822H LABEL-STICKER;W/W,ART PAPER,T0.05,50,10, 1 SNA
..2 ACCE1 BN96-13553D ASSY ACCESSORY;LS19CLNSB/XF 1 SA
...3 T0268 3903-000455 CBF-POWER CORD;DT,CN,IP3/Y(A),IEC320 C13 1 SA
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2,9.2 1 SNA
...3 T0527 AA68-00764A
LABEL-PASSING;SAMSUNG ALL,ART
PAPER,CLR,
1 SNA
...3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),50X15, 1 SNA
...3 BN68-01789A
MANUAL FLYER-WARRANTY CARD;Chinese,Art
1
1 SNA
...3 BN68-02528A
MANUAL FLYER-CHINA
MANUAL;Cobalt,SyncMas
1 SNA
...3 BN68-01118D
MANUAL-TCO 5.0 CARD;COMM,W/W,Mojo
80g,21
1 SNA
