38
Getting ready Getting ready
t
Mouthpiece/Microphone (upper)
*4
Mouthpiece/Microphone (upper) operates for handsfree
calling or recording (INTERVIEW), etc.
u
Volume key
Adjust ringtone volume and media sound volume.
Operate as the shutter while shooting a still picture and
video.
v
Bixby key
Start the "Bixby Home", and the information such as news
are organized and displayed.
w
Power key
Press and hold for over 2 seconds to turn the power on/o󱐯.
When the power is on, press to set screen lock.
x
Headset connection terminal
y
USB Type-C connection terminal
z
Mouthpiece/Microphone (lower)
*4
Mouthpiece/Microphone (lower) operates for speech
recognition such as calling, handsfree calling or recording,
etc.
A
Speaker
B
S Pen
Thisproductiscompatiblewith
"Okudake-Juden"Wirelessrecharging.
" おくだけ充電 (Okudake-Juden)"andthe
" おくだけ充電 (Okudake-Juden)"logoare
registeredtrademarksofNTTDocomo.
*1 Do not cover with the sticker, etc., Functions may not work
correctly.
*2 This product use it for both a mouthpiece and a speaker. The
volume will incrementally rise to the set volume so that loud sounds
do not come out of the speaker in your ears after the speakerphone
is switched to during calls, or after calls are nished.
*3 The antenna is built into the product. Covering around the antenna
by hand may a󱐯ect calling quality / communication quality.
*4 Be careful to not cover over the mouthpiece/microphones (upper/
lower) with your ngers, etc., while relevant functions are being used. In
addition, do not insert the SIM removal tool (sample) into the product
since this might cause damage.
a
Notication LED
Notify missed calls, indicate charging status, etc. only while
the display is turned o󱐯.
b
Iris recognition LED
*1
c
Proximity/Light sensor
*1
Turn o󱐯 display and adjust the display brightness
automatically when proximity of face is detected or according
to the ambient brightness. Also, operate this product by
detecting motion of hand (gesture).
d
Edge screen
e
Display (Touch panel)
The screen is curved on the both sides. Colors may look
di󱐯erent depending on what angle you are looking at the
curved screen.
The display is covered with a protective lm. To use a
commercially-available protective lm, remove the protective
lm on the display rst.
f
Receiver/speaker
*2
g
Front camera
h
Iris recognition camera
*1
i
GPS antenna part
*3
j
Rear camera
k
mark
l
Wireless charging position
Please align this position when perform wireless charging.
m
Wi-Fi
®
/Bluetooth
®
antenna part
*3
n
Flash/Light
o
Cardiac rate sensor
Measure cardiac rate by activating the "S Health" application
and holding up your nger.
p
Fingerprint recognition sensor
q
LTE Built-in antenna part
*3
r
au IC card/microSD memory card tray
s
Tray eject hole
The hole for inserting the SIM card removal tool (sample) to
retrieve the au IC card/microSD memory card tray.
