3 Disassembly and Reassembly
3-2 GH15LS/GH15ES/GH15MS
1. After confirm there is nothing
on the disk
Turn the LCD module over
and put it on a flat desk set to
the ground.
3-2 Replacement Order of Lamp Assemblies (GH15LS/GH15ES/GH15MS : Samsung Panel)
2. Push down the stopper and
slide the lamp unit.
3. Please take out the lamp
unit from the LCD
module.
To Next Page
