Flow Chart of Troubleshooting
9-8
This Document can not be used without Samsung's authorization
9-1-4.
Microphone Part
Is
t
he Microphone
assembled correctly?
Microphone does not work
Resold
er
the microphone
Resolder or replace
MIC300
END
No
Yes
Yes
Yes
Yes
No
MIC_BIAS
=2.1
V?
No
Check UCP200
Check the reference voltage on mic path
Check the connection MIC
Yes
Check mic-path connection
Resolder C317
