Samsung HT-C5200 Service Manual

Samsung Electronics 5-12
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
VC37 2203-006048 C-CER,CHIP 100nF,10%,10V,X7R,TP,1005 118 SA
VL6 2703-000398 INDUCTOR-SMD 10uH,10%,3225 1 SA
WR15B 2007-001044 R-CHIP 56ohm,5%,1/10W,TP,1608 4 SA
X202 2801-003843 CRYSTAL-SMD 18.432MHz,30ppm,SMD,20pF,50o 1 SA
X202 2801-004008 CRYSTAL-SMD 24MHz,20ppm,28-AAN,12pF,30oh 1 SA
X202 2801-004371 CRYSTAL-SMD 12.288MHz,50ppm,SX-1,18pF,50 1 SNA
ZRN10 2011-001261 R-NETWORK 33ohm,5%,1/16W,L,CHIP,8P,TP,2. 10 SA
ZVL3 3301-001495 BEAD-SMD 120ohm,2012,2500mA,TP,115ohm/10 3 SA
0202-001463 SOLDER-WIRE LFC2-W3.0,-,D3,99.79Sn/0.2Cu 6.171 SNA
0202-001477 SOLDER-CREAM LST309-M,D20~45um,96.5Sn/3A 1 SNA
0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0. 0.167 SNA
0202-001767 SOLDER-CREAM LST-5710,D20~38,Sn-57Bi-1Ag 2.788 SNA
0204-002420 SOLVENT 1M-1000,C3H70H,96 3.25 SNA
0204-002607 FLUX DF-234U,13%,14KG,Gravity 0.82 2.52 SNA
0403-001797 DIODE-ZENER NZH3V0B,2.85/3.15V,500mW,SOD 1 SNA
0904-002352 IC-DSP TMS320DA788B,TQFP,144P,20.2x20.2m 1 SA
1001-001298 IC-ANALOG SWITCH L10X,10P,2.1x1.6,1,1.65 4 SNA
1003-002187 IC-MOTOR DRIVER AM9268,SOP,42P,18x7.5mm, 1 SA
1003-002188 IC-MOTOR DRIVER AM9858,SOP,28P,18x7.5mm, 1 SNA
1006-001438 IC-BUS DRIVER R5H30201NA04NQ08,QFN,20P,4 1 SA
1107-001844 IC-NOR FLASH MX29LV160DTTI-70G,16Mbit,2M 1 SNA
1107-001887 IC-NAND FLASH NAND02GW3B2DN6,2Gbit,256Mx 1 SNA
1203-005469 IC-POWER SUPERVISOR MIC2009YM6,SOT-23,6P 1 SA
1203-005526 IC-DC/DC CONVERTER AOZ1025DIL,DFN,16P,5x 1 SA
1203-006067 IC-POWER SUPERVISOR TPS2553DBVR,SOT-23,6 1 SNA
1203-006104 IC-DC/DC CONVERTER MP8707EN,SOIC8E,8P,4. 2 SA
1204-003090 IC-VIDEO DECODER BCM7630,FCBGA,422P,19x1 1 SNA
1205-003160 IC-CODEC AK4113VF,VSOP,30P,9.7x5.6mm,PLA 1 SA
2007-000146 R-CHIP 6.8Kohm,5%,1/16W,TP,1005 1 SNA
2007-000606 R-CHIP 240ohm,1%,1/10W,TP,1608 4 SA
2007-000657 R-CHIP 27ohm,1%,1/10W,TP,1608 1 SA
2007-000946 R-CHIP 47ohm,1%,1/10W,TP,1608 1 SA
2007-001329 R-CHIP 7.5Kohm,5%,1/16W,TP,1005 1 SA
2007-002768 R-CHIP 6.2Kohm,1%,1/10W,TP,1608 1 SA
2007-002915 R-CHIP 4.02Kohm,1%,1/10W,TP,1608 1 SA
2007-007008 R-CHIP 300ohm,5%,1/16W,TP,1005 1 SNA
2007-007132 R-CHIP 15Kohm,1%,1/16W,TP,1005 1 SA
2007-007135 R-CHIP 18Kohm,1%,1/16W,TP,1005 2 SNA
2007-007313 R-CHIP 6.8Kohm,1%,1/16W,TP,1005 1 SA
2007-007315 R-CHIP 3.9Kohm,1%,1/16W,TP,1005 1 SNA
2007-007318 R-CHIP 1Kohm,1%,1/16W,TP,1005 2 SNA
2007-007334 R-CHIP 200Kohm,1%,1/16W,TP,1005 1 SNA
2007-007467 R-CHIP 12.1Kohm,1%,1/16W,TP,1005 1 SA
2007-007698 R-CHIP 5.1Kohm,1%,1/16W,TP,1005 1 SNA
2007-007798 R-CHIP 10ohm,1%,1/16W,TP,1005 8 SA
2007-008275 R-CHIP 30Kohm,1%,1/16W,TP,1005 2 SNA
2007-008453 R-CHIP 1.24Kohm,1%,1/16W,TP,1005 1 SNA
2011-001345 R-NETWORK 10Kohm,5%,1/16W,L,CHIP,8P,TP,2 3 SA
