Samsung HT-C5200 Service Manual

5-13 Samsung Electronics
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
2402-001185 C-AL,SMD 2.2UF,20%,50V,WT,TP,4.3X4.3X6MM 1 SA
2703-003426 INDUCTOR-SMD 4.7uH,20%,12x12mm 1 SA
3701-001293 CONNECTOR-HDMI 19P,2R,FEMALE,SMD-A,AU 3 SA
3707-001093 CONNECTOR-OPTICAL ANGLE-RX 1 SA
3710-002628 SOCKET-INTERFACE 18P,1R,0.5mm,SMD-A,NI 1 SNA
AH41-01304B PCB MAIN HT-C5500,FR-4,4,02,T1.2,238x142 1 SNA
AH97-04212A ASSY SMD HT-C5500,EDC(2.1ch) MAIN ASSY S 1 SNA
AH97-04213A ASSY MANUAL INSERT HT-C5500,ASSY MANUAL 1 SNA
AH97-04877A ASSY MICOM-MICOM IC HTB-C5500WWM-1003.01 1 SNA
AH97-04879A ASSY MICOM-MICOM IC HT-C6500,AH,EPF005N, 1 SNA
AH97-04880A ASSY MICOM-NOR FLASH BD-5500ROM-0015,201 1 SNA
AH97-04891A ASSY MICOM-NAND FLASH HTB-C5500/6500WWB- 1 SNA
AK62-00029B HEAT SINK-ES HT-C5500,A6063,Pushpin+Grea 1 SNA
MK01A AH94-02432B ASSY PCB KEY HT-C5500,BD HOME THEATER,FR 1 SNA
6MC22 2203-000975 C-CER,CHIP 47nF,10%,25V,X7R,TP,1608,- 5 SNA
AC510 3708-001618 CONNECTOR-FPC/FFC/PIC 5P,1mm,SMD-A,Sn-Pb 4 SA
AQ7 0504-000128 TR-DIGITAL FJV3103R,NPN,200mW,22K/22Kohm 3 SA
AQ8 0504-000156 TR-DIGITAL KSR2103,PNP,200MW,22K/22K,SOT 1 SA
AR164 2007-000076 R-CHIP 330ohm,5%,1/10W,TP,1608 6 SA
AR49 2007-000140 R-CHIP 1Kohm,5%,1/16W,TP,1005 13 SNA
AS420 3406-001146 SWITCH-ROTARY 5V DC,HOLLOW-SHAFT 1 SA
C102 2203-006158 C-CER,CHIP 100nF,10%,16V,X7R,1005 18 SNA
C125 2203-006361 C-CER,CHIP 10000nF,10%,10V,X5R,TP,2012 1 SC
C134 2203-000257 C-CER,CHIP 10nF,10%,50V,X7R,TP,1608 4 SA
CN353 3708-001994 CONNECTOR-FPC/FFC/PIC 15P,1mm,SMD-A,SN,N 1 SNA
FL261 3809-002351 FFC CABLE-FLAT 30V,80C,185mm,5P,1.0mm,UL 1 SA
FL261 3809-002357 FFC CABLE-FLAT 30V,80C,90mm,15P,1.0mm,UL 1 SA
FL261 3809-002359 FFC CABLE-FLAT 30V,80C,45mm,5P,1mm,UL206 1 SA
HDR7 2007-000139 R-CHIP 220ohm,5%,1/16W,TP,1005 2 SNA
IS01 1209-001866 IC-SENSOR SS501,SOT-26,6P,2.9x1.6mm,PLAS 1 SA
IS01A 1209-001864 IC-SENSOR TOUCHCORE1.0,QFN,20P,4x4mm,PLA 1 SNA
KAR7 2007-000120 R-CHIP 680ohm,5%,1/10W,TP,1608 1 SNA
KR7 2007-000402 R-CHIP 150ohm,5%,1/10W,TP,1608 1 SA
L0405 0601-002094 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm,1.6x 7 SA
L0405 0601-002705 LED SMD(SIDE VIEW),WHT,3.8x1.2x0.6mm,632 7 SA
L0405 0601-002706 LED SMD(SIDE VIEW),RED,3.8x1.2x0.6mm,632 1 SA
L0405 0601-002823 LED SMD(TOP VIEW),BLUE,3.5x2.7x1.8mm 4 SNA
MR166 2007-000119 R-CHIP 560ohm,5%,1/10W,TP,1608 4 SA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 8 SA
R104 2007-000148 R-CHIP 10Kohm,5%,1/16W,TP,1005 1 SA
R111 2007-000171 R-CHIP 0ohm,5%,1/16W,TP,1005 2 SNA
WL02 3301-001069 BEAD-SMD 120ohm,1.6x0.8x0.8mm,200mA,TP,, 5 SNA
0202-001477 SOLDER-CREAM LST309-M,D20~45um,96.5Sn/3A 0.189 SNA
0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0. 0.05 SNA
0406-001128 DIODE-TVS MLVS-0603-E08,50V 1 SA
2007-001316 R-CHIP 820ohm,5%,1/16W,TP,1005 1 SA
2007-007334 R-CHIP 200Kohm,1%,1/16W,TP,1005 8 SNA
AH41-01303A PCB-KEY HT-C5500,CEM-3,2,00,T1.6,160x190 1 SNA
