Samsung HT-C5200 Service Manual

Samsung Electronics 5-14
Exploded View & Part List
This Document can not be used without Samsung’s authorization.
Loc. No. Part No. Description Specification Qty. SNA Remark
AH97-04884A ASSY MICOM-MICOM IC HT_C5500_100111_R04, 1 SNA
AH97-04953A ASSY SMD C5500,ASSY SMD,KEY(XAA),2,AH94- 1 SNA
AH91-00115B ASSY SHIELD HT-C5200 1 SNA
FIL 0203-000007 TAPE-FILAMENT T0.15,L55M,TRP 0.3 SNA
T0268 3903-000403 CBF-POWER CORD AT,EU,CP2,HOUSING(2P),250 1 SA
MF01A AH94-02431C ASSY PCB FRONT HT-C5200,BD HOME THEATER, 1 SA
AAC1 2203-005249 C-CER,CHIP 100nF,10%,50V,X7R,TP,1608 9 SNA
AC510 3708-001666 CONNECTOR-FPC/FFC/PIC 28P,1MM,ANGLE,SN 1 SA
AD480 2203-000979 C-CER,CHIP 47nF,10%,50V,X7R,TP,2012 1 SNA
AF020 AH63-02108A FILTER-VFD HT-C5500,PC,0.5T,90,25,VIOLET 1 SNA
AH410 AH61-03026A HOLDER-VFD HT-C5500,ABS,2.5,89,19,BLK 1 SNA
AR30 2007-000074 R-CHIP 100ohm,5%,1/10W,TP,1608 3 SA
AS080 AH63-01262A SHEET SHEET,PC 1 SNA
AS088 AH63-01938B SHEET-FILTER HT-Z120,FABRIC,0.4,10,75,BL 1 SNA
C125 2203-006361 C-CER,CHIP 10000nF,10%,10V,X5R,TP,2012 3 SC
CN2 3722-002313 JACK-USB 4P/1C,AU30U,BLK,STRAIGHT,A TYPE 1 SA
CN353 3708-001994 CONNECTOR-FPC/FFC/PIC 15P,1mm,SMD-A,SN,N 1 SNA
D0254 0404-000002 DIODE-SCHOTTKY CMPSH-3,30V,100mA,SOT-23, 2 SA
DR10 2007-000113 R-CHIP 33ohm,5%,1/10W,TP,1608 2 SA
DR32 3301-000314 BEAD-SMD 120ohm,1.6x0.8x0.8mm,-,-,- 1 SNA
EV01 AH07-00260A VF DISPLAY HNV-09SS82T,HT-C5500,90.0*16. 1 SA
FL06 3809-002518 FFC CABLE-FLAT 30V,80C,220mm,28P,1.0mm,U 1 SA
HDC24 2402-000008 C-AL,SMD 47uF,20%,16V,GP,TP,6.6x6.6x5.4 1 SNA
L8 2703-000402 INDUCTOR-SMD 1uH,20%,3225 1 SNA
MROP1 2007-000090 R-CHIP 10Kohm,5%,1/10W,TP,1608 2 SA
PR6 2007-000072 R-CHIP 47ohm,5%,1/10W,TP,1608 1 SNA
R830 2007-000101 R-CHIP 82Kohm,5%,1/10W,TP,1608 1 SA
UIC2 0609-001189 MODULE REMOCON HORIZONTAL,16.4mm,TR 1 SC
0103-004628 RESIN-HIPS BK0020,HB,HIPS,High Flow HIPS 15 SNA
0202-001463 SOLDER-WIRE LFC2-W3.0,-,D3,99.79Sn/0.2Cu 3.471 SNA
0202-001477 SOLDER-CREAM LST309-M,D20~45um,96.5Sn/3A 0.189 SNA
0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0. 0.096 SNA
0203-001362 TAPE-DOUBLE FACE 0203-001362 1 SNA
0204-002420 SOLVENT 1M-1000,C3H70H,96 1.2 SNA
0204-002607 FLUX DF-234U,13%,14KG,Gravity 0.82 0.93 SNA
0406-001128 DIODE-TVS MLVS-0603-E08,50V 3 SA
1003-002194 IC-VFD PT6324-QL,QFP,52P,14.0x14.0mm,-40 1 SA
AH41-01305A PCB-FRONT HT-C5500,CEM-3,2,00,T1.6,238x1 1 SNA
AH97-04515A ASSY SMD 5500,BD HOME THEATER,FRONT(XAA) 1 SNA
AH97-04518A ASSY MANUAL INSERT HT-C5200,FRONT ASSY M 1 SNA
ACCE1 AH92-03270F ASSY ACCESSORY HT-C5200,EDC-1 1 SNA
REMO2 AH59-02303A REMOCON TM1051,MULTI 24P,49,3V,C5500-6 1 SA
M-CLEA AH68-01984A MANUAL-CLEANING HT-X200,ART PAPER 1 SNA
HT004 AH81-02286C A/S-EYEGLASS CLOTH HT-TXQ120,POLY-BLOOTH 1 SNA
CRA1A AH96-00051A ASSY MISC P-IPOD CRADLE HT-Z520,XAA,89*5 1 SA
