DIMENSIONS AND WEIGHTS
iDCS 500 BASIC SYSTEM HEIGHT WIDTH DEPTH WEIGHT
SINGLE CABINET
17.5" 22.5" 12" 35 lb.
EXPANDED SYSTEM: TWO CABINETS
35" 22.5" 12" 70 lb.
EXPANDED SYSTEM: THREE CABINETS
52.5" 22.5" 12" 105 lb.
DIGITAL KEYSET (ALL MODELS)
4.25" 8.50" 9" 2.563 lb.
ADD-ON MODULE
4.25" 4.25" 9" 1.188 lb.
DOOR PHONE
5" 3.88" 1.25" 6.8 oz.
ENVIRONMENTAL LIMITS
OPERATING TEMPERATURE
32–104 °F/0–40 °C
STORAGE TEMPERATURE
-13–158 °F/-25–70 °C
HUMIDITY
10%-90% non-condensing
CABLE REQUIREMENTS
EQUIPMENT CABLE AWG MAX FEET MAX METERS
DIGITAL KEYSET 1 PR. TWISTED 24 1300 400
ADD-ON MODULE 1 PR. TWISTED 24 1300 400
SINGLE LINE STATION 1 PR. TWISTED 24 3000 1 KM
DOOR PHONE 2 PR. TWISTED 24 330* 100
*This is the maximum distance a door phone can be from the DPIM. The DPIM can be up to 900 cable
feet from the KSU. The total distance must not exceed 1230 feet.
