Samsung iDCS500 - Keyset Led Indications; RESERVE POWER DURATION ESTIMATES (in Minutes)

3-4
Chapter 3
Specifications
KEYSET LED INDICATIONS
CONDITION LED COLOR LED ON LED OFF
LINE IDLE OFF – OFF
LINE IN USE RED/GREEN STEADY –
RECALL AMBER 500 ms 500 ms
CALL ON HOLD RED/GREEN 500 ms 500 ms
RINGING C.O. CALL GREEN 100 ms 100 ms
RINGING INTERNAL CALL GREEN 100 ms 100 ms
DND INDICATION RED 112 IPM for 500 ms 500 ms
OPERATOR CALLS RED 100 ms 100 ms
ANS/RLS (DND)* RED 112 IPM for 500 ms 500 ms
ANS/RLS (HDSET MODE) RED STEADY –
TRSF (FORWARD ALL) RED STEADY –
*Overrides headset mode
RESERVE POWER DURATION ESTIMATES
(in minutes)*
UPS CAPACITY IN VOLT AMPS (VA)
NO. OF PSUs
250 450 600 900 1250 2000
1 5 20 30 47 75 180
2 8 10 24 40 70
3 5 7 203664
4 132235
5 101325
6 5 10 20
*These are approximate values. Specific UPS devices, due to their internal construction,
can have greater or lesser values.
BATTERY CAPACITY IN AH
NO. OF PSUs
40 80 120 160 200 240
1 20XXXXX
21020XXXX
3 7 13 20 X X X
4 5 10 15 20 X X
5 4 8 121620X
6 3 7 10131620
*These are approximate values. Specific UPS devices, due to their internal construction,
can have greater or lesser values.
NOTE:
X denotes that this system configuration cannot charge batteries of this capacity.
