Samsung LA32D400E1 - Page 8

2-2
2. Product specications
Model LA22D400E1R
Feature
ATV, 1-HDMI, 1-Component, 1-A/V, D-SUB, 1-USB2.0 ሪ
Brightness : 300cd/m ሪ
2
High Contrast Ratio : 1,000:1 ሪ
Response Time : 5ms ሪ
Specications
Item Description
LCD Panel 22inch FHD
Scanning Frequency
Horizontal : 60 kHz ~ 73 kHz (Automatic)
Vertical : 50 Hz ~ 75 Hz (Automatic)
Display Colors 16.7M color
Maximum resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω , internally terminated
Input Sync Signal
H/V Separate, TTL, P. or N.
Maximum Pixel Clock rate
97.98 MHz (Typ 74.25 MHz)
Active Display
Horizontal/Vertical
18.77 x 10.56 inches (476.64 (H) x 268.11 (V) mm)
AC power voltage & Frequency AC 110V ~ 120V, 60 Hz
Power Consumption
Under 60W (Under 1W, Stand by)
Set Dimensions (W x D x H) 21.0 x 6.8 x 15.4 nchs (533.2x171.6x390.0 mm)_with stand
21.0 x 6.8 x 15.4 nchs (533.2x171.6x390.0 mm)_with stand
Set Weight 11.2 Ibs (5.1kg)_with stand
10.8 Ibs (4.9kg)_without stand
Stand Dimensions (W x D x H) 13.8 x 6.8 x 3.0 inchs (351.7 x 171.6 x 75.3 mm)
Stand Weight 0.5 Ibs (0.25kg)
TV System Tunning Frequency Synthesize (Refer to detailed Frequency Table)
System PAL, SECAM, NT4.43
Sound BG, DK, L/L’, NICAM, MPEG1, DD, DD+, HE-AAC
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Audio Spec. - MAX Internal speaker Out : Right => 3W, Left => 3W
- BASS Control Range : -8 dB ~ + 8dB
- TREBLE Control Range : -8 dB ~ +8 dB
- Headphone Out : 10 mW MAX
- Output Frequency : RF : 80 Hz ~ 15 kHz
A/V : 80 Hz ~ 20 kHz
Note: Dolby Digital
+
, Game Mode, Film Mode, Energy Saving, Anynet
+
