6 Electrical Parts List
6-31
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 C1134 2203-000715 C-CER,CHIP;3.3nF,10%,50V,X7R,1608 1 S.A
....4 C2213 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C3012 2203-006333 C-CER,CHIP;10000nF,20%,16V,X5R,TP,3216 1 S.A
....4 C1108 2409-001051 C-ORGANIC;82UF,20%,6.3V,WT,TP,6.3*5.9MM, 1 S.A
....4 C1115 2409-001051 C-ORGANIC;82UF,20%,6.3V,WT,TP,6.3*5.9MM, 1 S.A
....4 C1126 2409-001051 C-ORGANIC;82UF,20%,6.3V,WT,TP,6.3*5.9MM, 1 S.A
....4 C1141 2409-001051 C-ORGANIC;82UF,20%,6.3V,WT,TP,6.3*5.9MM, 1 S.A
....4 C1325_WX 2409-001051 C-ORGANIC;82UF,20%,6.3V,WT,TP,6.3*5.9MM, 1 S.A
....4 C2046 2409-001051 C-ORGANIC;82UF,20%,6.3V,WT,TP,6.3*5.9MM, 1 S.A
....4 C2099 2409-001051 C-ORGANIC;82UF,20%,6.3V,WT,TP,6.3*5.9MM, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 IC012 1203-002995 IC-POSI.ADJUST REG.;AP1117D-A,TO-252,3P, 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 R1112 2007-000402 R-CHIP;150ohm,5%,1/10W,TP,1608 1 S.A
....4 C1112 2203-000405 C-CER,CHIP;0.18nF,5%,50V,C0G,1608 1 S.A
....4 CN330 3711-006374 HEADER-BOARD TO CABLE;BOX,41P,2R,1.25mm, 1 S.A
....4 IC118 1204-002724 IC-VIDEO PROCESS;SVP-WX68,BGA,336P,27x27 1 S.A
....4 R1350 2007-000119 R-CHIP;560ohm,5%,1/10W,TP,1608 1 S.A
....4 R1131 2007-001135 R-CHIP;68ohm,5%,1/4W,TP,3216 1 S.A
....4 R1132 2007-001135 R-CHIP;68ohm,5%,1/4W,TP,3216 1 S.A
....4 C2164_WX 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 S.A
....4 C2165_WX 2203-000384 C-CER,CHIP;0.015nF,5%,50V,C0G,1608 1 S.A
....4 T0077 BN41-00813B PCB MAIN;iDTV BORDEAUX PLUS, JASMINE, TU 1 S.N.A
....4 D1436 0403-000258 DIODE-ZENER;BZX84C5V6,5.2-6V,225mW,SOT-2 1 S.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45§-,96.5Sn/ 4.57 S.N.A
....4 M0018 BN97-01590B ASSY MICOM;T-TLPMPEUD-1008,N30A,2007.3.2 1 S.N.A
.....5 IC115 1107-001453 IC-FLASH MEMORY;29W160E,16Mbit,2Mx8/1Mx1 1 S.N.A
....4 M0018 BN97-01388A ASSY MICOM;T-BDXPDEU00-1004,N30A,2007.03 1 S.N.A
.....5 IC115 1107-001415 IC-FLASH MEMORY;29W320D,4Mx8/2Mx16Bit,TS 1 S.N.A
....4 M0018 BN97-01388C ASSY MICOM;T-BDPMPEUS-1004,N30A,T-CALMPE 1 S.N.A
.....5 IC520 0903-001485 IC-MICROCONTROLLER;44P,12x12mm,24MHz,TR, 1 S.N.A
....4 IC1302_WX 1205-003256 IC-RECEIVER;SiI9125CTU(Rev0.3),TQFP,144P 1 S.A
...3 JA1406_OP 3701-001400 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,Ni 1 S.A
...3 T0603 BN63-02494A SHIELD-PCB MAIN;MOSEL 40",SPTE,T0.3,EURO 1 S.N.A
...3 CCMM1 BN73-00024D SILICON/RUBBER;BORDEAUX,SILICON,28x28XT6 1 S.N.A
...3 T0603 BN63-03197A SHIELD-PCB MAIN;TULIP PAL,SPTE,T0.5 1 S.N.A
...3 CCMM1 BN73-00151A SILICON/RUBBER;GP1500 380MIL,20X20X9.5T 1 S.N.A
...3 M0131 BN63-03550A GASKET;BORDEAUX PLUS,Conductive Fabric,1 1 S.N.A
0.1 BN91-01420A ASSY SHIELD-SPE;LE37M86BDX/* 1 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 6 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 8 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 M2893 BH39-00362G LEAD CONNECTOR;SONOMA,UL1007#26,5PIN,100 1 S.A
..2 M2893 BN39-00802A LEAD CONNECTOR;LE32R86BDX,UL1007#26,UL/C 1 S.A
..2 M2893 BN39-00822A LEAD CONNECTOR-LVDS;LE37M86BD,51P/41P,40 1 S.A
..2 T0764 BN44-00157A SMPS-LCDTV;MK37,SEM,AC/DC,280W,AC100 ~ 2 1 S.A
..2 M0146 BN61-02241A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
..2 M0146 BN61-02242A BRACKET-PANEL SIDE;Bordeaux 37,SECC,T1.2 1 S.N.A
..2 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 2 S.N.A
..2 M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
..2 BN61-02952B HOLDER-SIDE AV;07 COMMON,EO,ABS+PMMA,HB, 1 S.N.A
..2 M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
..2 T0447 BN96-04680C ASSY BRACKET P-PANEL;37M87,AUO,NT,PAL 1 S.N.A
...3 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 2 S.A
...3 T0101 BN61-02968A BRACKET-WALL;40 BORDEAUX PLUS,SECC,T1.2, 1 S.N.A
