6 Electrical Parts List
6-82
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
0 LE52M87BDX/BWT LE52M87BD,N30A/52M80-GTU,52,LCD-TV,RUSSI 0
0.1 M0001 BN90-01160B ASSY COVER FRONT;52M87,EO(IDTV),-,ABS+PM 1 S.N.A
..2 T0175 BN96-04772A ASSY SPEAKER P;8ohm,4pin,Enclosure Type, 1 S.A
..2 T0003 BN96-04651J ASSY COVER P-FRONT;52M87,EO(IDTV),ABS+PM 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 AA60-00091P SPACER-FELT;,FELT,500X10,BLK,T0.5 2 S.N.A
...3 T0069 AA60-00171L SPACER-FELT;46L3,FELT,460,T0.5,10 2 S.N.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 2.21 S.N.A
...3 BN63-03035B COVER-DECORATION L;40M81,ABS,HB,IV-16,LE 1 S.N.A
...3 BN63-03036B COVER-DECORATION R;40M81,ABS,HB,IV-16,RI 1 S.N.A
...3 M0112 BN63-03203B COVER-FRONT;52M81,EO(IDTV),ABS+PMMA,-,-, 1 S.N.A
...3 T0022 BN64-00550A KNOB-CONTROL;40M81,ABS,-,-,-,HB,IV-16,-, 1 S.N.A
...3 T0066 BN96-04652C ASSY COVER P-DECORATION;52M81,SO,-,ABS,H 1 S.N.A
....4 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
....4 T0056 BN63-03209B COVER-DECORATION;52M81,ABS,-,-,-,HB,-,IV 1 S.N.A
....4 BN63-03212A COVER-DECORATION SUB;52M81,ABS+PMMA,-,-, 1 S.N.A
....4 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
....4 T0023 BN64-00548A KNOB POWER;TULIP40,PC VIOLET,V0 1 S.N.A
....4 T0054 BN64-00549A KNOB-DECORATION;40M81,ABS,-,-,-,HB,IV-16 1 S.N.A
....4 BN61-03261C BOSS-TAPE;Tulip,ACRYL,T1.1,W24mm,GRAY,TA 1.07 S.N.A
...3 M0146 BN96-04884D ASSY BOARD P-POWER & IR;LNT4642HX/XAA,CT 1 S.A
...3 M0145 BN96-04901A ASSY BOARD P-FUNCTION;LNT3771FD,CT5000-4 1 S.A
0.1 M0002 BN90-01165B ASSY COVER REAR;52M81,EO(IDTV),-,ABS+PMM 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 17 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 M0013 BN96-04720A ASSY COVER P-REAR;52M81,EO(IDTV),-,ABS+P 1 S.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 1.1 S.N.A
...3 M0006 BN63-03207A COVER-REAR;52M81,EO(IDTV),ABS+PMMA,-,-,- 1 S.N.A
...3 T0071 BN64-00555B INLAY-TERMINAL;07,COMMON,EO(IDTV),PS SHE 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,PP,V0,BLK 1 S.N.A
..2 C/REAR+H/W 6011-001610 BOLT-ETC;M8,L18,ZPC(BLK),SWRCH18A,WSP,PH 4 S.N.A
0.1 M0216 BN90-01170A ASSY STAND;46,52M81,-,ABS+PMMA,HB,BK23,H 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0013 BN96-04648A ASSY STAND P-BASE;46,52M81,-,ABS+PMMA,HB 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 8 S.A
...3 BN61-02533A HOLDER-SWIVEL RING;46M7 EO,ACETAL,NATUAL 1 S.N.A
...3 BN61-02534A HOLDER-SWIVEL RING;46M7 EO,ACETAL,NATUAL 1 S.N.A
...3 BN61-02536A BRACKET-HINGE SWIVEL;46M7 EO,HG,T3.0 1 S.N.A
...3 T0920 BN61-03005A GUIDE-STAND;TULIP46,ABS V0,BLK 1 S.N.A
....4 T0514 BN61-02537A BRACKET-SUPPORT;46M7,SECC,T2.0 2 S.N.A
...3 BN61-03006A BRACKET-STAND BOTTOM;TULIP46,SECC,T3.0 1 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.45 S.N.A
...3 T0004 BN63-03137A COVER-STAND BASE;TULIP46,ABS+PMMA,HB,BK2 1 S.N.A
...3 T0132 BN73-00052A RUBBER FOOT;ARES 17,SILICON,DIA 17 * T1. 4 S.N.A
0.1 BN91-01403C ASSY LCD-AMLCD;LNT5261FX/* 1 S.N.A
..2 M0215 BN07-00394A LCD-PANEL;LTA520HA03,10bit,52inch,1.07B, 1 S.A
0.1 M0017 BN91-01407D ASSY CHASSIS;LE52M86BDX/* 1 S.N.A
..2 M0014 BN94-01206D ASSY PCB MAIN;LE52M86BDX/* 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 JA3201_OP 3709-001477 CONNECTOR-CARD SLOT;68P,1.27mm,ANGLE,AU, 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN906 3711-004182 CONNECTOR-HEADER;BOX,10P,1R,2MM,STRAIGHT 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-005842 HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR 1 S.A
...3 JA1601_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA1608_EU 3722-000498 JACK-SCART;21P,-,SN,BLK,NO 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 JA333 3722-002360 JACK-PIN;3P,AU,GRN/BLU/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 JA333 3722-002362 JACK-PIN;2P,Sn,WHT/RED,STRAIGHT 1 S.A
...3 CIS3 BN40-00096A TUNER;DNOS403MH261B(S),PAL Hyper,181CH, 1 S.A
...3 T0174 BN97-01420D ASSY SMD;LE52M86BDX/* 1 S.N.A
....4 D1204 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1208 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1209 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
6-4 LE52M86BDX Parts List
