Samsung LE37M86BDX - Page 41

6 Electrical Parts List
6-36
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 T0087 1203-003696 IC-POSI.FIXED REG.;NCP1117DT18T5G,DPAK,3 1 S.A
....4 IC1809 1203-004363 IC-VOL. DETECTOR;RT9818C-29PV,SOT-23,3P, 1 S.A
....4 IC1303 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC3001 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 S.A
....4 IC1113 1203-004379 IC-DC/DC CONVERTER;AP1530SA,SOP,8P,5x3.9 1 S.A
....4 IC3101 1204-002697 IC-DECODER;STx5105,PBGA,324P,23x23mm,PLA 1 S.A
....4 IC1202 1204-002719 IC-AUDIO PROCESSOR;SGTV5810,LQFP,100P,14 1 S.A
....4 IC118 1204-002729 IC-VIDEO PROCESS;S4LF119X01,PBGA,208P,17 1 S.A
....4 IC2002_WX 1205-003185 IC-RECEIVER;MST3560M-LF-170,PQFP,128P,20 1 S.A
....4 D1471 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1481 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1491_NSID 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1612 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1613 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1614 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 D1809 1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 S.A
....4 R1527 2007-000042 R-CHIP;499ohm,1%,1/10W,TP,1608 1 S.A
....4 R2139 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2226 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2227 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1903 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1904 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1905 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1906 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1907 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1908 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1909 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1910 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1941 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1944 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1993_LCD 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1111 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 R2206 2007-000060 R-CHIP;100Kohm,1%,1/10W,TP,1608 1 S.A
....4 R1266 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1311_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1331_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1332_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1341_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1342_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1343_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1418 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1456 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1464 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1501_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1502 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1507_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1519 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1524 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1525 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1526_NSID 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1542 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1543 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1550 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1553 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1554 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1555 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1556 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1557 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1558 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1559 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1574 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1575 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1576 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1578 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1581_NSID 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1584 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1585 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1586_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1587_HDMI 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1621_EU 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1655 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1676_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1677_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1678_WX 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1708_NMMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1709_NMMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1710_NMMS 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1805 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1826 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1827 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1828 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R1830 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
