6 Electrical Parts List
6-80
Level Loc. No. Code No. Description & Specification Q'ty SA/SNA
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 7 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 1 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 1 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 1 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 10 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 6 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 M0174 BN44-00166A IP BOARD;IP-301135A,46" TULIP,30mA,75mA, 1 S.A
..2 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 3 S.N.A
..2 M0146 BN61-02887A BRACKET-PANEL TOP;TULIP,40,SECC,T1.2,-,- 2 S.N.A
..2 M0107 BN63-03039A SHIELD-COVER;MURANO40,PCM,T0.5,IDTV 1 S.N.A
..2 BN63-03146A SHIELD-SMPS;TULIP46,SECC,T0.5 1 S.N.A
..2 BN61-03007B HOLDER-WALL;TULIP46,ABS,HB 2 S.N.A
...3 INSERT BN61-02932A BRACKET-STOPPER NUT;SUM24L 2 S.N.A
..2 M2893 BN39-00763A LEAD CONNECTOR;LNS4696DX,UL3239#24,UL/CS 1 S.A
..2 M2893 BN39-00802F LEAD CONNECTOR;LE46S86BDX,UL1007#26,24PI 1 S.A
..2 M2893 BN39-00823A LEAD CONNECTOR-LVDS;LE40M86BD,51P/41P,40 1 S.A
..2 T0275 BN96-04938A ASSY MISC P-INLET;LNT4661FX/XAA,250/250M 1 S.N.A
..2 M2893 BH39-00362B LEAD CONNECTOR;RE32**,UL1007#26,5P,150mm 1 S.A
..2 M2893 BN39-00830A LEAD CONNECTOR;LNT4642HX/XAA,UL1061#28,7 1 S.A
..2 M2893 BN39-00764A LEAD CONNECTOR;LNS4696DX,UL3239#24,UL/CS 1 S.A
..2 M0131 BN63-03008A GASKET;LN46M71BD,Conductive Fabric,18mm, 1 S.N.A
..2 T0447 BN96-05214B ASSY BRACKET P-PANEL;46M81,EO 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 3 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.N.A
...3 MP1.4 BN61-03009A BRACKET-BOTTOM;TULIP46,SECC,T1.2,BRACKET 1 S.N.A
...3 T0081 BN61-03010A BRACKET-MAIN;TULIP46,SECC,T1.2,BRACKETLE 1 S.N.A
...3 BN61-03011A BRACKET-GUIDE POWER;TULIP46,SECC,T1.2,RI 1 S.N.A
...3 BN61-03012A BRACKET-GUIDE POWER;TULIP46,SECC,T1.2,LE 1 S.N.A
...3 M0115 BN61-03013A BRACKET-STAND LINK;TULIP46,SECC,T1.6 1 S.N.A
...3 M0131 BN63-03508A GASKET;LE46M87BDX,Conductive Fabric,12,1 1 S.N.A
...3 M0131 BN63-03509A GASKET;LE46M87BDX,Conductive Fabric,9,13 1 S.N.A
..2 M0020 BN96-05039Q ASSY BOARD P-SIDE HDMI A/V;LE46M87BDX/XE 1 S.N.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 BN61-03047C HOLDER-SIDE AV;46M81,EO,ABS+PMMA,HB,-,-, 1 S.N.A
...3 M0020 BN96-04922E ASSY BOARD P-SIDE A/V;TULIP 46",SJ07-01- 1 S.N.A
..2 M0596 BN96-05167A ASSY MISC P-FLAT CABLE;JASMINE,350mm 1 S.A
0.1 M0045 BN92-02426B ASSY ACCESSORY;LE46M86BDX/XEC 1 S.N.A
..2 M0045 BN96-04835B ASSY ACCESSORY;LE37M86BDX/XEC 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2 1 S.N.A
...3 ACCESSORY AA68-03242E MANUAL FLYER-02;SAFETY GUIDE;All Model,S 1 S.N.A
...3 ACCESSORY AA68-03575A MANUAL FLYER-02,REGISTRATION C;XEU,ENG,U 1 S.N.A
...3 ACCESSORY AA68-03575B MANUAL FLYER-02,REGISTRATION C;XEG,GERMA 1 S.N.A
...3 ACCESSORY AA68-03575C MANUAL FLYER-02,REGISTRATION C;XEF,FRENC 1 S.N.A
...3 ACCESSORY AA68-03575D MANUAL FLYER-03,REGISTRATION C;XEC,SPANI 1 S.N.A
...3 ACCESSORY AA68-03575E MANUAL FLYER-04,REGISTRATION C;XET,ITALY 1 S.N.A
...3 ACCESSORY AA68-03575F MANUAL FLYER-02,REGISTRATION C;XEN,DUTCH 1 S.N.A
...3 ACCESSORY AA68-03575G MANUAL FLYER-02,REGISTRATION C;XEP,PORTU 1 S.N.A
...3 ACCESSORY BN68-00514C MANUAL FLYER-WARRANTY CARD,03;comm,Samsu 1 S.N.A
...3 M0156 BN68-01186B MANUAL USERS-01;COMM,SAMSUNG,E/Fr/Ge/D/I 1 S.N.A
..2 M0045 BN96-04835C ASSY ACCESSORY;LE46M86BDX/XEC 1 S.A
...3 T0268 3903-000145 CBF-POWER CORD;DT,EU,FP3/YES,U(IEC C13-R 1 S.A
...3 T0524 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,28,2 1 S.N.A
...3 T0074 BN59-00603A REMOCON;BORDEAUX PLUS,TM87C,samsung 28p+ 1 S.A
...3 ACCESSORY BN63-01798A CLOTH-CLEAN;RE40**,CLOTH,180,200,RHCM 1 S.N.A
...3 T0531 BN63-03148B COVER-BOTTOM;46,52M81,HIPS,HB,BK500 1 S.A
0.1 M0001 BN90-01159H ASSY COVER FRONT;46M86,EO(IDTV),ABS+PMMA 1 S.N.A
..2 T0003 BN96-04649H ASSY COVER P-FRONT;46M86,EO(IDTV),ABS+PM 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 2.21 S.N.A
...3 T0056 BN63-03035C COVER-DECORATION;40M81,ABS,-,-,-,HB,-,IV 1 S.N.A
...3 T0056 BN63-03036C COVER-DECORATION;40M81,ABS,-,-,-,HB,-,IV 1 S.N.A
...3 M0112 BN63-03128B COVER-FRONT;46M81,EO(IDTV),ABS+PMMA,-,-, 1 S.N.A
...3 T0066 BN96-04647D ASSY COVER P-DECORATION;46M81,-,ABS,HB,I 1 S.N.A
....4 T0060 BN61-01655A SPRING ETC;STS-304 SUS,D8,L12,T0.5 1 S.N.A
....4 T0056 BN63-03131C COVER-DECORATION;46M81,ABS,-,-,-,HB,-,IV 1 S.N.A
....4 T0056 BN63-03168A COVER-DECORATION;46M81,ABS+PMMA,-,-,-,HB 1 S.N.A
....4 T0059 BN64-00366A INDICATOR LED;ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
....4 T0023 BN64-00548A KNOB POWER;TULIP40,PC VIOLET,V0 1 S.N.A
