5. Exploded View & Part List
5-24. LE52B75* Parts List
Level Location No. Code No. Description & Specifi cation Q’ty SA/SNA Remark
LE52B750U1WXXC LE52B750U1W,N68A/52BU1-G7U,52,LCD-TV,SPA
0.1 M0001 BN90-01964B ASSY COVER FRONT;52,LB750,EO,CHARCOAL GR 1 S.N.A
..2 T0175 BN96-09463D ASSY SPEAKER P;8ohm,4pin,10W,R:250/ L:70 1 S.A
..2 T0003 BN96-09635B ASSY COVER P-FRONT;52,LB750,EO,PC(CLR)+P 1 S.N.A
...3 H/B/SIDE+C 6003-001188 SCREW-TAPTYPE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.N.A
...3 T0069 AA63-60122T SPACER-FELT;52L650,FELT,1150,T0.5,25 2 S.N.A
...3 T0069 BN60-00027S SPACER-FELT;L650 52,FELT,650,0.35,25 2 S.N.A
...3 BN61-04661A BRACKET-STOPPER;L650,SK-5,T0.4,Plating,H 6 S.N.A
...3 M0279 BN63-00866A FELT;AS17UO,FELT,0.5,10,140 2 S.N.A
...3 CCM1 BN63-02183F COVER-SHEET;Rhcm,PE Vinyl,T0.05,900mm,20 0.75 S.N.A
...3 CCM1 BN63-05199B COVER-SHEET;AMBER,PE,T0.08,W65mm,200M,CL 3.7 S.N.A
...3 CCM1 BN63-05199F COVER-SHEET;AMBER,PE,T0.08,W95mm,200M,CL 1.5 S.N.A
...3 M0112 BN63-05263B COVER-FRONT;52,LB750,EO,PC(CLR)+PC(C/GRA 1 S.A
....4 BN81-00116D RESIN-TOC;PC V0,TTP01,CLR,TN-1030(NP),TH 0.952 S.N.A
....4 BN81-00265E RESIN;ToC PC, TGR02,TN-1030S, LD046,TH30 1.227 S.N.A
...3 BN64-01022A DECORATION-BOTTOM;UB7000,PC,clear 1 S.N.A
....4 BN81-00116J RESIN;PC CLEAR,SC-1220R/70918,HF-1130R, 0.13 S.N.A
...3 BN96-09513C ASSY HOLDER P-BOSS SIDE RIGHT;52,LB650,P 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.03 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.54 S.N.A
....4 BN61-04806C HOLDER-BOSS SIDE R;52,LB650,ABS+PMMA,HB, 1 S.N.A
.....5 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.213 S.N.A
...3 BN96-09513D ASSY HOLDER P-BOSS SIDE LEFT;52,LB650,PM 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.1 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.03 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.54 S.N.A
....4 BN61-04806D HOLDER-BOSS SIDE L;52,LB650,ABS+PMMA,HB, 1 S.N.A
.....5 BN81-00204P RESIN-HIGH GLOSS;HAM 8560,SF-0505,K21294 0.213 S.N.A
...3 BN96-09651B ASSY HOLDER P-BOSS BOTTOM;52,LB750,HIPS, 1 S.N.A
....4 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.5 S.N.A
....4 BN61-04731D BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.99 S.N.A
....4 BN61-04731F BOSS-TAPE;AMBER,ACRYL,T1.1,W6.0mm,WHITE, 0.19 S.N.A
....4 BN61-04810B HOLDER-BOSS BOTTOM;52,LB750,HIPS,HB,BK50 1 S.N.A
.....5 BN81-00199H RESIN;HIPS HB,BK500,HF-1690H,K2901 0.267 S.N.A
...3 M0175 BN96-10210E ASSY BOARD P-TOUCH FUNCTION&IR;LN40B750U 1 S.N.A
0.1 M0216 BN90-01989A ASSY STAND;52,LB750,BLACK,CLEAR NECK 1 S.N.A
..2 M0027 BN96-09481A ASSY STAND P-BASE;52,LB750,TEMPERED GLAS 1 S.N.A
...3 B/S/STAND+ 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 6 S.N.A
...3 G/STAND+G/ 6003-001003 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 BN61-04692A BOSS-PRIMER;#94,clear,35cps 0.001 S.N.A
...3 BN61-04731B BOSS-TAPE;AMBER,ACRYL,T1.1,W12.0mm,WHITE 1 S.N.A
...3 T0920 BN61-04997A GUIDE-STAND;LB750 52,PC+GF 20%,BLK 1 S.N.A
....4 BN81-00204H RESIN;Trirex,3025G20 BK,ABS+PC G/F 20%,4 493.9 S.N.A
...3 BN61-05240A HOLDER-SWIVEL RING TOP;LB700 46,POM HB,A 1 S.N.A
...3 BN61-05243A BRACKET-STAND BOTTOM;LB700 46,HGI,T3.0 1 S.N.A
...3 BN61-05244A BRACKET-SWIVEL BOTTOM;LB700 46,HGI,T3.0 1 S.N.A
