Samsung Electronics 7-3
Ref. No. Parts No. Description/Specification Q'ty Remarks
38 DE71-60301B COVER-AIR;PP(FB53) 20G M530/M540 SEAU 1
39 4713-001046 LAMP-INCANDESCENT;240V,104mA,25W,ORG,-,- 1
40 DE03-30066A MAGNETRON;OM52SH(31)ESM 700W MIN3.8 1
41 DE47-20009A THERMOSTAT;CS-7SA(160/60)187Y 250V7.5A 1 1
42 DE31-10155F MOTOR-FAN;SMF-540EA 230V/50HZ 2350 1
43 DE71-60117A COVER-BLOWER;PP-JI350 41G WHT MU3250W 1
44 DE91-40045C ASSY NOISE FILTER;DNA-1018D-1(C) 250V 10 1
45 DE39-30074B ASSY WIRE LEAD-C;L170 1
46 DE34-10139D SWITCH-MEMBRANE;PET 240V/50HZ W87.5 L121 1
47 DE93-20022E ASSY BODY LATCH;M530/M540 NYLON#66(2021S 1
48 ASSY DOOR;BUTTON GE-WHT M530/M540 SEAU 1
49 ASSY CONTROL-BOX;240V/50HZ M540/XSA SEAU 1
50 DE93-30413A ASSY CONTROL-PANEL;240V/50HZ M540/XSA SE 1
51 DE61-50128A BRACKET-COVER MOTOR;SGCC1-Z T0.8 W122 L9 1
Exploded Views and Parts List
7-2 Main Parts List
Parts No. Description / Specification Q'ty Remarks
DE60-30016A NUT-FLANGE;M4 MSWR10 2 MO/FAN
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 MEM-PN
DE02-00081A TAPE-OPP;OPP T0.07 W50 TRP OSCA 1 P-CASE
DE60-10080A SCREW-WASHER;M5 L12 2S 4 HVT
DE60-10082J SCREW-TAPPING;TH 2S-4X8 MSWR3 ZPC YEL WS 1 B/HVC
DE60-10082J SCREW-TAPPING;TH 2S-4X8 MSWR3 ZPC YEL WS 1 NO-FIL
DE60-10098A SCREW-ASSY TAPTITE;PH TC M4X8 SWRCH18A Z 2 MO/DRI
DE60-10098A SCREW-ASSY TAPTITE;PH TC M4X8 SWRCH18A Z 2 SW-THE
DE60-20014A BOLT-FLANGE;M5 L10 MSWR3 FEFZY 2 HI-LOW
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 B-PLTE
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 P-CORD
DE60-10069A SCREW-TAP TH;TH M4 L10 FRFZY 1 B/H-U
DE60-10069A SCREW-TAP TH;TH M4 L10 FRFZY 1 CV/AIR
DE60-10069A SCREW-TAP TH;TH M4 L10 FRFZY 1 CV/BLW
DE60-20014A BOLT-FLANGE;M5 L10 MSWR3 FEFZY 2 HI-UPP
DE60-10080A SCREW-WASHER;M5 L12 2S 4 MGT
DE60-10082I SCREW-A;2S-4X12 FEFZY 3 B-PLTE
DE60-10082I SCREW-A;2S-4X12 FEFZY 2 BD-LAT
DE60-10082I SCREW-A;2S-4X12 FEFZY 1 C-BOX
DE60-10082I SCREW-A;2S-4X12 FEFZY 1 CV/BLW
DE60-10082I SCREW-A;2S-4X12 FEFZY 4 PN/OUT
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 N-F-EA
