Samsung Electronics 7-3
Ref. No. Parts No. Description/Specification Q'ty Remarks
D 1 DE64-40252A DOOR-A;ABS T2.5 W402 L258 WHT G643C 1
D 2 DE64-40006A DOOR-KEY;POM(TC3005) T2.0 12GR BLK CE9 1
D 3 DE61-70033A SPRING-KEY;ES HSWR10 PI0.6 D6.0 L22.3 BL 1
D 4 DE01-00003A FILM-DOOR;PE-FILM T0.15 W143 L265 M745 1
D 5 DE92-50126D ASSY DOOR-E;M745 BLK ASSY PURCHASING 1
D 6 DE64-40008B DOOR-C;PP T1.5 W L G BLK CE745G 1
D 7 DE67-20158C SCREEN-DOOR;ACRYL T1.5 W372.5 L197.8 WHT MW 1
D 8 DE02-00125A TAPE-DOUBLE FACE;ACRYL T0.45 W9 WHT WF103 1
Ref. No. Parts No. Description/Specification Q'ty Remarks
C 1 DE66-20171A BUTTON-PUSH;ABS WHT G643C 1
C 2 DE61-70076A SPRING-BUTTON;HSWR PI0.6 1
C 3 DE34-10213A SWITCH-MEMBRANE;PET 230V50HZ W89.4 L156.4 M 1
C 4 DE67-40142A WINDOW-DISPLAY;ACRYL BLK G643C 1
C 5 DE72-70164A CONTROL-PANEL;ABS WHT T2.5 G643C 1
C 6 DE91-10383A ASSY P.C.B-MAIN;230V50HZ N LED M745 1
C 7 DE93-30383F ASSY CONTROL-PANEL;G643C P/WHT HR-0370 1
Exploded Views and Parts List
7-4 Control Parts List
7-3 Door Parts List
Parts No. Description / Specification Q'ty Remarks
DE60-10098A SCREW-ASSY TAPTITE;PH TC M4X8 SWRCH18A Z 2 MO/DRI
DE60-10088A SCREW-TAP PH;PH M3 L8 FEFZY PLAIN 2 PCB
DE60-10098A SCREW-ASSY TAPTITE;PH TC M4X8 SWRCH18A Z 1 HVD
DE60-10082H SCREW-A;2S-4X12 TOOTHED 2 CON-BX
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 MEM-PN
DE60-10098A SCREW-ASSY TAPTITE;PH TC M4X8 SWRCH18A Z 1 CV-TCO
DE60-10082H SCREW-A;2S-4X12 TOOTHED 2 CV/BLW
DE60-10082H SCREW-A;2S-4X12 TOOTHED 1 CV/AIR
DE60-10082H SCREW-A;2S-4X12 TOOTHED 2 BD-LA
DE60-10082H SCREW-A;2S-4X12 TOOTHED 4 B-PLTE
DE60-10082A SCREW-A;M4 L12 2S TOOTHED 4 OUT-PN
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 B/DR-M
DE60-10080A SCREW-WASHER;M5 L12 2S 4 MGT
DE60-10080A SCREW-WASHER;M5 L12 2S 4 HVT
DE60-10098A SCREW-ASSY TAPTITE;PH TC M4X8 SWRCH18A Z 2 MGT-TC
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 P-CO-E
DE60-10033A SCREW-TH;TH + M4 L10 MSWR10 FEFZY 2 HI-UPP
DE02-00125A TAPE-DOUBLE FACE;ACRYL T0.45 W9 WHT WF10 1 DOOR-A
DE60-10033A SCREW-TH;TH + M4 L10 MSWR10 FEFZY 2 HI-LOW
DE60-10012A SCREW-TAP TITE;TH + 3 M4 L10 SWR10 ZPC2 1 N/FILT
