1. Precaution
1-1. Safety Precaution (A )
1) Pacemaker wearers must consult their physician before attempting to service or repair a microwave oven.
For additional advice on this subject, write to the manufacturer of your pacemaker.
2) The product should be serviced only by qualified personnel.
3) Though the product has been manufactured in compliance with the Federal performance Standard 21 CFR Subchapter J(DHHS), it is very
important when servicing to avoid being exposed to excessive microwave radiation. All the repairs should be performed in accordance with
the procedures described in this manual.
4) Use only the identical parts as listed in the parts list of this manual in order to comply with the Federal performance Standard 21 CFR
Subchapter J(DHHS).
5) In the event of suspected microwave energy leakage in excess of 5mW/cm2, please notify;
SAMSUNG ELECTRONIC COMERCIAL
IBERICA.S.A
VIA AUGUSTA,PARCELA103
08184 PALAU DE PLEGAMANS
BARCELONA,ESPANA
6) Repair microwave oven at no charge to the owner for excessive microwave emission level.
7) Ascertain the cause of the excessive leakage and instruct the owner not to use the unit until the oven has been brought into compliance.
8) If the oven is operated with the door open, please advise the owner not to use the oven and contact the manufacturer and CDRH immediately.
9) There are special components used in the microwave oven which are important for safety. These parts are marked with a on the replacement
parts list. It is essential that these critical parts should be replaced only with the manufacturer's specified parts to prevent microwave
leakage, shock, fire, or other hazards. Do not modify the original design.
1-2. Servicing Precaution ( )
PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY
1. Do not operate or allow the oven to be operated with the door
open.
2. Make the following safety checks on all ovens to be serviced
before activating the magnetron or other microwave source, and
then make repairs as necessary:
(A) Interlock operation
(B) proper door closing
(C) seal and sealing surfaces (arcing, wear, and other damage)
(D) damage to or loosening of hinges and latches
(E) evidence of dropping or abuse.
3. Before turning on microwave power for any service test or
inspection within the microwave generating compartments, check
the magnetron, wave guide or transmission line, and cavity for
proper alignment, integrity, and connections.
4. Any defective or misadjusted components in the interlock, monitor,
door seal, and microwave generation and transmission systems
shall be repaired, replaced, or adjusted by procedures described in
this manual before g the oven to the owner.
5. A Microwave leakage check compliance with the Federal
performance standard should be performed on each oven prior to
release to the owner.
2. Specifications
SPECIFICATIONS
TIMER
POWER SOURCE
POWER CONSUMPTION
OUTPUT POWER
OPERATING FREQUENCY
MAGNETRON
COOLING METHOD
OUTSIDE DIMENSIONS
99 MINUTES 90 SECONDS
230V 50Hz, AC
MICROWAVE: 1,300W
GRILL: 1.000W
FROM 75W TO 750W, FROM 80 TO 800W (10 LEVEL POWER)
(IEC-705 TEST PROCEDURE) •
2,450MHz
0M75S(31)
COOLING FAN MOTOR
489(W)x 275(H) x 364(D)
POWER LEVEL
ON TIME
OFF TIME'
%
M6Q45
ON TIME
OFF TIME'
10%
80W 4 sec
26 sec
20%
160W
7 sec 23 sec
30%
240W
10 sec
20 sec
40%
320W 13 sec 17 sec
50%
400W 16 sec Msec
60%
480W
19 sec
11 sec
70%
560W 22 sec
8 sec
80%
640W
25 sec 5 sec
90%
720W
28 sec 2 sec
100%
800W
30 sec 0 sec
1
To Next Page
