TR8 2007-000822 R-CHIP;390ohm,5%,1/10W,DA,TP,2012
TR9 2007-000468 R-CHIP;1Kohm,5%,1/10W,DA,TP,2012
VC2L 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012,
VC2R 2203-000595 C-CERAMIC,CHIP;220pF,5%,50V,NPO,TP,2012,
VR1L 2007-000300 R-CHIP;10Kohm,5%,1/10W,DA,TP,2012
VR1R 2007-000300 R-CHIP;10Kohm,5%,1/10W,DA,TP,2012
VR2L 2007-001177 R-CHIP;8.2Kohm,5%,1/10W,DA,TP,2012
VR2R 2007-001177 R-CHIP;8.2Kohm,5%,1/10W,DA,TP,2012
AH93-30005N ASSY-MAIN,TAPG;MAX870,MAIN,AUTO DOM S.N.A
AC1L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
AC1R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
AC21 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
AC22 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
AC3L 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
AC3R 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
AC4L 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC4R 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
AC5L 2201-000619 C-CERAMIC,DISC;5pF,0.3pF,50V,CH,TP,7x4,5
AC5R 2201-000619 C-CERAMIC,DISC;5pF,0.3pF,50V,CH,TP,7x4,5
AC6 2401-000385 C-AL;10UF,20%,100V,GP,-,6.3X11,2.5M
AC7 2401-000385 C-AL;10UF,20%,100V,GP,-,6.3X11,2.5M
AC8 2401-000385 C-AL;10UF,20%,100V,GP,-,6.3X11,2.5M
AC9 2401-000385 C-AL;10UF,20%,100V,GP,-,6.3X11,2.5M
AC9L 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
AC9R 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
AD10 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
AD11 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
AD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
AD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
AD4 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
AD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
AD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
AQ10 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92
AQ11 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9
AQ1L 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9
AQ1R 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9
AQ3 0504-000146 TR-DIGITAL;KSR2004,PNP,300MW,47K-47K,TO-
AQ4 0504-000203 TR-DIGITAL;KSR1004,NPN,300MW,47K-47K,TO-
AQ7 0504-000146 TR-DIGITAL;KSR2004,PNP,300MW,47K-47K,TO-
AQ8L 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9
AR10 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR11 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR12 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR13 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8x3.2mm
AR14 2001-000028 R-CARBON(S);100ohm,5%,1/2W,AA,TP,2.4x6.4
AR15 2001-000028 R-CARBON(S);100ohm,5%,1/2W,AA,TP,2.4x6.4
AR16 2001-000588 R-CARBON;3.3Kohm,5%,1/4W,AA,TP,2.4x6.4m
AR17 2001-000588 R-CARBON;3.3Kohm,5%,1/4W,AA,TP,2.4x6.4m
AR1L 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR1R 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR20 2001-000786 R-CARBON;47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR21 2001-000786 R-CARBON;47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR3L 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
AR4L 2001-000858 R-CARBON;56KOHM,1%,1/8W,AD,TP,1.8X3.2MM
AR6L 2001-000858 R-CARBON;56KOHM,1%,1/8W,AD,TP,1.8X3.2MM
AR6R 2001-000858 R-CARBON;56KOHM,1%,1/8W,AD,TP,1.8X3.2MM
AR8 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
AR8L 2003-000468 R-METAL OXIDE(S);10OHM,5%,1W,AA,TP,3.3X9
AR8R 2003-000468 R-METAL OXIDE(S);10OHM,5%,1W,AA,TP,3.3X9
AZD1 0403-000363 DIODE-ZENER;UZ6.8BH,6.8V,6.8-7.2V,500MW
AZD2 0403-000363 DIODE-ZENER;UZ6.8BH,6.8V,6.8-7.2V,500MW
DC0 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
DC1 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
DC10 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
DC12 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
DC13 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
DC14 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
DC15 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
DC16 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
DC18 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
DC23 2401-001895 C-AL;100uF,20%,16V,GP,6.3x11mm,2.5m
DC3 2401-001887 C-AL;100NF,20%,50V,-,TP,4X7MM,5
DC4 2401-001887 C-AL;100NF,20%,50V,-,TP,4X7MM,5
DC5 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
DC6 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
DC7 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
DQ1 0504-000203 TR-DIGITAL;KSR1004,NPN,300MW,47K-47K,TO-
DQ2 0504-000146 TR-DIGITAL;KSR2004,PNP,300MW,47K-47K,TO-
DQ3 0504-000203 TR-DIGITAL;KSR1004,NPN,300MW,47K-47K,TO-
DR10 2001-001000 R-CARBON;82KOHM,5%,1/8W,AA,TP,1.8X3.2MM
DR12 2001-000563 R-CARBON;27Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR18 2001-000515 R-CARBON;220ohm,5%,1/8W,AA,TP,1.8x3.2mm
DR20 2001-000411 R-CARBON;18Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR21 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR22 2001-000472 R-CARBON;2.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
DR27 2001-000660 R-CARBON;33Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR28 2001-000660 R-CARBON;33Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR3 2001-000515 R-CARBON;220ohm,5%,1/8W,AA,TP,1.8x3.2mm
DR35 2001-000273 R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m
DR36 2001-000273 R-CARBON;100Kohm,5%,1/8W,AA,TP,1.8x3.2m
DR43 2003-000500 R-METAL OXIDE(S);150ohm,5%,1W,AA,TP,3.3x
DR44 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR5 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR7 2001-000522 R-CARBON;22Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DR71 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
DR72 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
DR73 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
DR8 2001-000786 R-CARBON;47Kohm,5%,1/8W,AA,TP,1.8x3.2mm
DZD1 0403-000354 DIODE-ZENER;UZ5.1B,5.1V,4.8-5.4V,500MW,D
FC1 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
FC10L 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
FC10R 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
FC11L 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
FC11R 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
FC1L 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC1R 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC2 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
FC2L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC2R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC3 2401-001102 C-AL;330UF,20%,16V,GP,TP,8X12,5
FC3L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC3R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC4 2401-000475 C-AL;10UF,20%,50V,GP,-,5X11,2MM
FC4L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
FC4R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
Electrical Parts List
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
Samsung Electronics 8-3
