FC5 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,
FC5L 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
FC5R 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
FC6L 2301-000453 C-FILM,PEF;5.6NF,10%,50V,TP,5.5X7X3MM,5M
FC6R 2301-000453 C-FILM,PEF;5.6NF,10%,50V,TP,5.5X7X3MM,5M
FC7L 2301-000393 C-FILM,PEF;18NF,10%,50V,TP,6.5X12.5X3.5M
FC7R 2301-000393 C-FILM,PEF;18NF,10%,50V,TP,6.5X12.5X3.5M
FC8L 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,
FC8R 2301-000412 C-FILM,PEF;22NF,10%,50V,TP,6.5X10.5X4MM,
FC9L 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
FC9R 2301-000375 C-FILM,PEF;100NF,5%,50V,TP,11X12.5X6.5,7
FD1 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41
FQ1 0504-000146 TR-DIGITAL;KSR2004,PNP,300MW,47K-47K,TO-
FQ1L 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
FQ1R 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
FR1 2001-000111 R-CARBON;150ohm,5%,1/4W,AA,TP,2.4x6.4mm
FR2 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR4L 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
FR7L 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR7R 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
FR8R 2001-000472 R-CARBON;2.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
FRONT AH41-10537A PCB-MAIN MAX870;MAX870,1L,FR-1,330*247*1
HC1 2401-001364 C-AL;470UF,20%,16V,GP,TP,10X12MM,5M
HC1L 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
HC1R 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
HC2 2401-001364 C-AL;470UF,20%,16V,GP,TP,10X12MM,5M
HC2L 2401-000240 C-AL;100UF,20%,10V,GP,TP,6X11MM,5MM
HC2R 2401-000240 C-AL;100UF,20%,10V,GP,TP,6X11MM,5MM
HC4 2401-001954 C-AL;4.7UF,20%,50V,GP,BK,5X11MM,5
HD1 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41
HD2 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41
HD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
HD4 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
HD5 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
HD6 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
HQ1L 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9
HQ1R 0501-000407 TR-SMALL SIGNAL;KSD471A-Y,NPN,800mW,TO-9
HR1 2004-000207 R-METAL;100ohm,5%,1/4W,AA,TP,2.4x6.4mm
HR1L 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR1R 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR2 2001-000027 R-CARBON;100ohm,5%,1/4W,AA,TP,2.4x6.4mm
HR2L 2001-000003 R-CARBON;330ohm,5%,1/8W,AA,TP,1.8x3.2mm
HR3 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR5L 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR5R 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
HR6L 2001-000302 R-CARBON;10ohm,5%,1/8W,AA,TP,1.8x3.2mm
HR6R 2001-000302 R-CARBON;10ohm,5%,1/8W,AA,TP,1.8x3.2mm
RC0 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
RC12 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
RC13 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
RC14 2401-001572 C-AL;47UF,20%,50V,GP,-,6.3X11,2.5MM
RC16 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,
RC17 2201-000161 C-CERAMIC,DISC;10nF,+80-20%,500V,Y5V,TP,
RC19 2401-001919 C-AL;2.2UF,20%,50V,-,TP,4X7MM,5
RC2 2401-001938 C-AL;22UF,20%,25V,GP,BK,5X11MM,2MM
RC3 2401-000438 C-AL;10UF,20%,25V,GP,-,5X11,2MM
RC5 2401-001938 C-AL;22UF,20%,25V,GP,BK,5X11MM,2MM
RD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
RD3 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15
RD4 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41
RD5 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41
RD6 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-41
RD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
RQ12 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,80V,60V,700m
RQ4 0501-000296 TR-SMALL SIGNAL;KSA709-Y,PNP,800mW,TO-92
RQ5 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,80V,60V,700m
RQ7 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,80V,60V,700m
RR1 2001-000362 R-CARBON;150ohm,5%,1/8W,AA,TP,1.8x3.2mm
RR11 2001-000019 R-CARBON(S);10ohm,5%,1/2W,AA,TP,2.4x6.4m
RR12 2004-000903 R-METAL;4.7KOHM,5%,1/2W,AA,TP,3.3X9MM
RR19 2001-000780 R-CARBON;470ohm,5%,1/8W,AA,TP,1.8x3.2mm
RR20 2001-000613 R-CARBON;3.9Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR21 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X3.2M
RR22 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR23 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
RR24 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP,2.4X6.4M
RR26 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
RR27 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR28 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR3 2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
RR4 2001-000802 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X3.2M
RR8 2001-001178 R-CARBON(S);680ohm,5%,1/2W,AA,TP,2.4x6.4
RZD1 0403-000399 DIODE-ZENER;UZP9.1B,9.1V,8.5-9.6V,1W,DO
RZD3 0403-000357 DIODE-ZENER;UZ5.6BM,5.6V,5.4-5.8V,500MW
RZD4 0403-000357 DIODE-ZENER;UZ5.6BM,5.6V,5.4-5.8V,500MW
RZD5 0403-000564 DIODE-ZENER;TZP16A,16V,15.3-17.1V,1W,DO-
RZD6 0403-000564 DIODE-ZENER;TZP16A,16V,15.3-17.1V,1W,DO-
TC10 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,2.5
TC101 2202-000796 C-CERAMIC,MLC-AXIAL;1nF,10%,50V,Y5P,TP,3
TC13 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC15 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TC17 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC18 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
TC19 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC20 2401-001022 C-AL;3.3UF,20%,50V,GP,-,5X11,2MM
TC21 2202-000854 C-CERAMIC,MLC-AXIAL;47NF,30%,50V,Y5R,TP,
TC22 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
TC25 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC29 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
TC31 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
TC32 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC33 2401-001912 C-AL;1uF,20%,50V,GP,5x11mm,2mm,BK
TC36 2401-002189 C-AL;330uF,20%,10V,GP,BK,8x11.5mm,5
TC39 2401-001968 C-AL;470NF,20%,50V,GP,TP,5X11MM,5
TC4 2401-001975 C-AL;47UF,20%,16V,GP,TP,5X11MM,5
TC40 2401-000303 C-AL;100uF,20%,25V,GP,TP,6.3x11,2.5
TC9 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
TD1 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
TD2 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
TD3 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
TD4 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
TD7 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
TD8 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,500mW,
TQ2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250MW,TO-92
TQ3 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250MW,TO-92
TQ4 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800mW,TO-92
TQ5 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
TQ6 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250mW,TO-92,T
Electrical Parts List
Location no. Code no. Description & Specifiation Remarks Location no. Code no. Description & Specifiation Remarks
8-4 Samsung Electronics
