C123 2401-000419 C-AL;10UF,20%,16V,GP,-,4X7,5
C801 2401-000795 C-AL;220UF,20%,16V,GP,-,8X11.5,3.5M
C301 2401-001102 C-AL;330UF,20%,16V,GP,TP,8X12,5
C114 2401-001238 C-AL;4.7uF,20%,25V,GP,BK,3x5,1mm
C501L 2401-001238 C-AL;4.7uF,20%,25V,GP,BK,3x5,1mm
C501R 2401-001238 C-AL;4.7uF,20%,25V,GP,BK,3x5,1mm
C120 2401-001324 C-AL;470nF,20%,50V,GP,BK,3x5,1mm
C135 2401-001324 C-AL;470nF,20%,50V,GP,BK,3x5,1mm
Q101 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,TP,90-
WIC201 0904-001524 IC-DSP;5L9290,-,QFP,48P,472MIL,16.9344MHz,TR,CM
WIC301 1003-000179 IC-MOTOR DRIVER;KA9258D,SOP,28P,-,SINGLE,-,ST,
WIC602 1105-001339 IC-DRAM;11L1644,4Mx4Bit,TSOP,24P,300MIL,50nS,3.3
WIC601 1204-001798 IC-DECODER;S5L9274X01-E0R0,LQFP,64P,-,PLASTIC,3.3V,
WIC101 1204-001799 IC-ASP;KB9226,LQFP,48P,393MIL,PLASTIC,5.5V,-,-2
J12 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J4 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J7 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J8 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J9 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J1 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
J10 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
J11 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
J13 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
J14 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
J2 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
J3 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
J5 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R201 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
R203 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
R502L 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
R502R 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
R210 2007-000075 R-CHIP;220ohm,5%,1/16W,DA,TP,1608
R204 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R205 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R206 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R207 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R208 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R209 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R213 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R601 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R602 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R603 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R801 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R802 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R811 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R812 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R807 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R808 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R809 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R132 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R133 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R114 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R121 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R116 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
R123 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R129 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R813 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R120 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
R126 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
R101 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R102 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R103 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R104 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R119 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R127 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R128 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R501L 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R501R 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R105 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608
R106 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608
R124 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608
R125 2007-000103 R-CHIP;120Kohm,5%,1/16W,DA,TP,1608
R118 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
R202 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
R107 2007-000115 R-CHIP;82ohm,5%,1/16W,DA,TP,1608
R110 2007-000129 R-CHIP;27Kohm,5%,1/16W,DA,TP,1608
R113 2007-000132 R-CHIP;180Kohm,5%,1/16W,DA,TP,1608
R108 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
R115 2007-001179 R-CHIP;8.2Kohm,5%,1/16W,DA,TP,1608
R112 2007-001196 R-CHIP;820Kohm,5%,1/16W,DA,TP,1608
C115 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C116 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C118 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C124 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C131 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C132 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C204 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C205 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C211 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C403 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C604 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C606 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C607 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C610 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C611 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C612 2203-000178 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,1608,
C103 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C104 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C121 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C129 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C130 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C134 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C207 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C209 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C213 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C214 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C216 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C218 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C304 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C305 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C401 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C402 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C601 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C602 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,1608
C102 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C117 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C502L 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C502R 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
C126 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608,-
C201 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,1608
C202 2203-000681 C-CERAMIC,CHIP;0.027nF,5%,50V,NP0,TP,1608
C803 2203-000783 C-CERAMIC,CHIP;0.33nF,5%,50V,NP0,TP,1608
C105 2203-000800 C-CERAMIC,CHIP;33nF,10%,25V,X7R,TP,1608
C119 2203-000800 C-CERAMIC,CHIP;33nF,10%,25V,X7R,TP,1608
C128 2203-000800 C-CERAMIC,CHIP;33nF,10%,25V,X7R,TP,1608
C208 2203-000851 C-CERAMIC,CHIP;0.039nF,5%,50V,NP0,TP,1608
C111 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C112 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C124A 2203-001063 C-CERAMIC,CHIP;56nF,10%,16V,X7R,TP,1608,-
C106 2203-001140 C-CERAMIC,CHIP;68nF,10%,16V,X7R,TP,1608,-
C122 2203-001140 C-CERAMIC,CHIP;68nF,10%,16V,X7R,TP,1608,-
C203 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608,-
C605 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608,-
C608 2203-001222 C-CERAMIC,CHIP;820pF,10%,50V,X7R,TP,1608,-
C127 2203-001607 C-CERAMIC,CHIP;0.22nF,5%,50V,NP0,TP,1608
C125 2203-001640 C-CERAMIC,CHIP;0.39nF,10%,50V,X7R,TP,1608
CMS300-P CMS300,CD MECHA;XINXING,CMS300,MAXN25
*****
MAXL68 Parts List *****
AH26-00102A TRANS POWER E174*62MM,EI
AH38-10001A FM-WIRE 1007#22,1500MM
AH39-00021A LEAD-CONNECTOR ASSY UL1533#28,300MM
AH39-00257G POWER CORD MAX980,-,CP2,250V,2.5A,1650mm/
AH39-20002D LEAD-CONNECTOR ASS’Y 5264,-,3P,300MM,2970#33
AH40-00008A TUNER-PACK KST-MB114LS1-50,FM/MW/LW,-,-,-
AH42-20001Q LOOP-ANT KS980214,18.5UH,CONNECTOR-2P
AH59-00004P REMOCON ASSY AR4022
AH92-00893B ASSY PCB-FRONT MAX-L65,FRONT PCB ASSY
UD1 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD10 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD11 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD12 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD13 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD14 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD5 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UD9 0401-000101 DIODE-SWITCHING 1N4148,100V,200mA,500mW,4nS
UQ20 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
UQ21 0501-000398 TR-SMALL SIGNAL KSC945-YTA,NPN,60V,50V,150MA,
UQ14 0501-000610 TR-SMALL SIGNAL KSA928A,PNP,-30V,-30V,-2A,1W
UQ16 0501-000610 TR-SMALL SIGNAL KSA928A,PNP,-30V,-30V,-2A,1W
UQ18 0501-000610 TR-SMALL SIGNAL KSA928A,PNP,-30V,-30V,-2A,1W
UQ1 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ10 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ11 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ12 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ13 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ15 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ17 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ19 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ2 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ22 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ3 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ4 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ5 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ7 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ8 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ9 0504-000118 TR-DIGITAL KSR1003TA,NPN,300MW,22K-22KOHM
UQ6 0504-000122 TR-DIGITAL KSR1009TA, 300MW,4.7KOHM,TO-9
ULD1 0601-001232 LED LTL-1CHKES-UA,GRN,555NM,2.5MM
ULD10 0601-001232 LED LTL-1CHKES-UA,GRN,555NM,2.5MM
ULD11 0601-001232 LED LTL-1CHKES-UA,GRN,555NM,2.5MM
Location no Code no. Description Specifiation Remarks Location no Code no. Description Specifiation Remarks
3-6 Samsung Electronics
