Samsung Electronics 3-1
AH26-00236A TRANS POWER;-,MAX-ZS750,230V, MAX-W(Z)S750
AH26-00236B TRANS POWER;-,MAX-ZS750,127V,60HZ MAX-W(Z)S750,MEXICO
AH26-00236C TRANS POWER;-,MAX-ZS750,120/240V MAX-W(Z)S750
AH26-00236D TRANS POWER;-,MAX-ZS750,230/245V MAX-W(Z)S750
AH26-00236E TRANS POWER;-,MAX-ZS750,220V,60HZ MAX-W(Z)S750,KOREA
AH26-00234A TRANS POWER;-,MAX-ZS730,230V, MAX-W(Z)S730,EU
AH26-00234B TRANS POWER;-,MAX-ZS730,127V,60HZ MAX-W(Z)S730,MEXICO
AH26-00234C TRANS POWER;-,MAX-ZS730,120/240V MAX-W(Z)S730,ASIA
AH26-00234D TRANS POWER;-,MAX-ZS730,230/245V MAX-W(Z)S730
AH26-00234E TRANS POWER;-,MAX-ZS730,220V,60HZ MAX-W(Z)S730,KOREA
AH39-00257A POWER CORD;CP2,250V,2.5A,1830MM CP2(VDE)
AH39-00258Q POWER CORD;BS,250V,2.5A,1830MM BS(U.K)
AH39-00257D POWER CORD;KS,250V,2.5A,1830MM KS(KOREA)
AH39-00258H POWER CORD;UL/CSA,125V,10A,1830MM EP2(UL/CSA)
AH39-00258H POWER CORD;IRAM,AP2,125V,10A,1830MM AP2(ARGENTINA)
AH39-00258B POWER CORD;SAA,AP2,125V,17.5A,1830MM AP2(AUSTRALIA)
AH39-00320C CBF COAXIAL CABLE;MAX-L68,110REC,-,1007# COMMON
AH42-20001P ANT LOOP;-,KS971120-01,18.5UH##10%,- COMMON
AH59-00162A DECK;CMS300-V COMMON
AH40-00043A TUNER-PACK ASSY;FM/MW/LW,RDS,FM87.5~108.0MHz EUROPE(RDS)
AH40-00042A TUNER-PACK ASSY;FM/MW/LW,RDS,FM64~108.0MHz CIS(RDS)
AH40-00044A TUNER-PACK ASSY;FM/MW,MW520~1720KHz ASIA(T-BAND)
AH40-00045A TUNER-PACK ASSY;FM/MW/LW,FM64~108.0MHz CIS(NO RDS)
AH40-00046A TUNER-PACK ASSY;FM/MW/LW,FM87.5~108.0MHz LW BAND
AH40-00049A TUNER-PACK ASSY;FM/MW/SW1/SW2 SW BAND
AH59-00134L REMOCON-ASSY;MAX-WS730/750,SAMSUNG,27KEY MAX-WS730/750 BASIC
AH59-00134M REMOCON-ASSY;MAX-WS730/750,SAMSUNG,27KEY MAX-WS730/750 LATIN
AH59-00134N REMOCON-ASSY;MAX-ZS750,SAMSUNG,27KEY MAX-ZS750 BASIC
AH59-00134W REMOCON-ASSY;MAX-ZS750,SAMSUNG,27KEY MAX-ZS750 LATIN
AH97-01111A ASSY-CA’DECK;-,MAX-S720,ASSY CA’DECK 1 AUTO REVERSE
6002-000396 SCREW-TAPPING;BH,+,2,M2,L5,ZPC(WHT),SWCH
AH61-00413B BRACKET-DECK;MAX-B550,SPTE 0.3T,0.3T,-,-
AH39-00021A LEAD CONNECTOR ASSY;UL1533#28,300MM,-,-,
AH39-20002D LEAD CONNECTOR ASSY;5264,-,3P,300MM,2970
AH59-01145A DECK-CASSETTE;ADR268AMW1,MAXS560,-,-,DC1
AH97-01115A ASSY-CA’DECK;-,MAX-WS730/750,ASSY TAPE D 2 AUTO REVERSE
6002-000396 SCREW-TAPPING;BH,+,2,M2,L5,ZPC(WHT),SWCH
AH61-00413B BRACKET-DECK;MAX-B550,SPTE 0.3T,0.3T,-,-
AH39-00021A LEAD CONNECTOR ASSY;UL1533#28,300MM,-,-,
AH39-00052N LEAD CONNECTOR ASSY;RX-DV9,#1007,28AWG,-
AH59-01146A DECK-CASSETTE;ADR268FTW1,MAXWS750,-,-,DC
AH92-00922A ASSY PCB-CD;G3HI-3CD,3.5S COMMON
WIC402 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,D
WIC401 1003-001162 IC-MOTOR DRIVER;KA3082,SIP,10PIN,25MIL,D
X201 2802-000211 RESONATOR-CERAMIC;16.93MHz,0.5%,TP,10.0x
CW103 3708-001131 CONNECTOR-FPC/FFC/PIC;5P,1.25mm,STRAIGHT
CW101 3708-001252 CONNECTOR-FPC/FFC/PIC;16P,1mm,STRAIGHT-F
CW105 3708-001438 CONNECTOR-FPC/FFC/PIC;22P,1.25mm,ANGLE,S
CW107 3711-000906 CONNECTOR-HEADER;BOX,3P,1R,2mm,ANGLE,SN
CW104 3711-003379 CONNECTOR-HEADER;NOWALL,3P,1R,2.5mm,STRA
CW106 AH39-00060A LEAD CONNECTOR ASSY;-,51015-08,51004-08,
CW102 AH39-20561P LEAD CONNECTOR ASSY;-,5295,PHR,6P,150mm,
D301 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO-15,T
ZD301 0403-000344 DIODE-ZENER;UZ3.9B,3.9V,3.7-4.1V,500mW,D
ZD402 0403-000352 DIODE-ZENER;UZ4.7BM,4.7V,4.4-5.0V,500mW,
ZD401 0403-000361 DIODE-ZENER;UZ6.2BSB,6.2V,5.99-6.24V,500
Q302 0501-000010 TR-SMALL SIGNAL;KSC1008,NPN,800mW,TO-92,
Q101 0501-000314 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23,
Q301 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO-92L,
IC201 0904-001524 IC-DSP;5L9290,-,QFP,48P,472MIL,16.934
IC301 1003-000179 IC-MOTOR DRIVER;KA9258D,SOP,28P,-,SINGLE
IC101 1204-001799 IC-ASP;KB9226,LQFP,48P,393MIL,PLASTIC
2001-000290 R-CARBON;10Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R117 2001-000331 R-CARBON;12Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R810 2001-000362 R-CARBON;150ohm,5%,1/8W,AA,TP,1.8x3.2mm
R803 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R807 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R808 2001-000734 R-CARBON;4.7Kohm,5%,1/8W,AA,TP,1.8x3.2m
R302 2001-001006 R-CARBON;82ohm,5%,1/8W,AA,TP,1.8x3.2mm
R114 2007-000001 R-CHIP;68KOHM,5%,1/10W,DA,TP,2012
J4 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J3 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J2 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J10 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J1 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J9 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J8 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J7 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
J5 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
R501L 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
R501R 2007-000282 R-CHIP;100KOHM,5%,1/10W,DA,TP,2012
R201 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
R502L 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
R502R 2007-000290 R-CHIP;100OHM,5%,1/10W,DA,TP,2012
R809 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R133 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R132 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
MR3 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
MR2 2007-000300 R-CHIP;10KOHM,5%,1/10W,DA,TP,2012
R108 2007-000308 R-CHIP;10OHM,5%,1/10W,DA,TP,2012
R124 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
R125 2007-000338 R-CHIP;120KOHM,5%,1/10W,DA,TP,2012
R110 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
R121 2007-000409 R-CHIP;15KOHM,5%,1/10W,DA,TP,2012
R113 2007-000444 R-CHIP;180KOHM,5%,1/10W,DA,TP,2012
R811 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R806 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R805 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R804 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R209 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R204 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R205 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R206 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R207 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R208 2007-000468 R-CHIP;1KOHM,5%,1/10W,DA,TP,2012
R204 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
R118 2007-000477 R-CHIP;1MOHM,5%,1/10W,DA,TP,2012
R116 2007-000546 R-CHIP;20KOHM,5%,1/10W,DA,TP,2012
R210 2007-000572 R-CHIP;220OHM,5%,1/10W,DA,TP,2012
R128 2007-000653 R-CHIP;27KOHM,5%,1/10W,DA,TP,2012
DR2 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
DR1 2007-000872 R-CHIP;4.7KOHM,5%,1/10W,DA,TP,2012
R813 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
R129 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
R123 2007-000941 R-CHIP;47KOHM,5%,1/10W,DA,TP,2012
R126 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R120 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R104 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R103 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R102 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R101 2007-001039 R-CHIP;56KOHM,5%,1/10W,DA,TP,2012
R115 2007-001177 R-CHIP;8.2KOHM,5%,1/10W,DA,TP,2012
R112 2007-001195 R-CHIP;820KOHM,5%,1/10W,DA,TP,2012
R127 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
R119 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
R106 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
R105 2007-001208 R-CHIP;82KOHM,5%,1/10W,DA,TP,2012
R107 2007-001216 R-CHIP;82OHM,5%,1/10W,DA,TP,2012
R301 2008-000140 R-FUSIBLE;2.2ohm,5%,1/2W,AA,TP,3.5x9.4mm
C806 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3.
C805 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3.
C804 2202-000243 C-CERAMIC,MLC-AXIAL;33pF,5%,50V,SL,TP,3.
C603A 2202-000780 C-CERAMIC,MLC-AXIAL;100nF,+80-20%,50V,Y5
C113 2202-000780 C-CERAMIC,MLC-AXIAL;100nF,+80-20%,50V,Y5
2202-000781 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P,TP
C131 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C132 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C204 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C205 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C211 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C130 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C115 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C116 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C118 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C124 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C129 2203-000203 C-CERAMIC,CHIP;100nF,10%,16V,X7R,TP,2012
C218 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C216 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C214 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C304 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C305 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C401 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C402 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C103 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C105 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C121 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C134 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C207 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C209 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C213 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012
C126 2203-000495 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,2012
C127 2203-000595 C-CERAMIC,CHIP;0.22NF,5%,50V,C0G,TP,2012
C803 2203-000787 C-CERAMIC,CHIP;0.33NF,5%,50V,C0G,TP,2012
C128 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012
C119 2203-000802 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,2012
C125 2203-000840 C-CERAMIC,CHIP;0.39NF,5%,50V,C0G,TP,2012
C208 2203-000858 C-CERAMIC,CHIP;0.039NF,5%,50V,C0G,TP,201
C111 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012
C112 2203-000892 C-CERAMIC,CHIP;4.7NF,10%,50V,X7R,TP,2012
Location no Code no. Description Specifiation Remarks
Location no Code no. Description Specifiation Remarks
3. Electrical Parts List
*S.N.A. : Service Not Available
