Samsung Electronics 2-3
* Parts List of Total Exploded view
No. Code No. Description Specification Q’ty REMARK No. Code No. Description Specification Q’ty REMARK
1 AH64-02214M CABINET-FRONT MIPS L/GRAY 1 2MIC(silver)
AH64-02214N MIPS L/GRAY 1 2MIC(latin sound silver)
AH64-02214P MIPS L/GRAY 1 NO MIC(silver)
AH64-02214Q MIPS L/GRAY 1 2MIC(gray)
AH64-02214R MIPS L/GRAY 1 2MIC(latin sound gray)
AH64-02214S MIPS L/GRAY 1 NO MIC(gray)
AH64-02214T MIPS L/GRAY 1 NO MIC,NO RDS(gray)
AH64-02214U MIPS L/GRAY 1 NO MIC,NO RDS(silver)
2 AH64-02216C DOOR-CD ABS L/GRAY 1 silver
AH64-02216B ABS L/GRAY 1 gray
3 AH64-02219E DECO-DOOR CD ABS L/GRAY 1 ZS750G
AH64-02214P ABS L/GRAY 1 ZS730G
AH64-02214F ABS L/GRAY 1 WS730(silver)
AH64-02214M ABS L/GRAY 1 MQ-WS730S
AH64-02214N ABS L/GRAY 1 WS730
AH64-02214S ABS L/GRAY 1 WS750
AH64-02214T ABS L/GRAY 1 WS750S
4 AH63-00501A SHEEFT-VFD PC 0.4T 1
5 AH64-02225B WINDOW-VFD PMMA BROWN 1 WS750/WS730
AH64-02225C PMMA BROWN 1 ZS750/ZS730
6 AH64-02220B DECO-DOOR.CASS L ABS L/GRAY 1 silver
AH64-02220C ABS L/GRAY 1 auto reverse(silver)
AH64-02220D ABS L/GRAY 1 gray
AH64-02220E ABS L/GRAY 1 auto reverse(gray)
7 AH64-02221B DECO-DOOR.CASS R ABS L/GRAY 1 silver
AH64-02221C ABS L/GRAY 1 gray
8 AH64-02217B DOOR-CASS.L ABS L/GRAY 1 gray
AH64-02217C ABS L/GRAY 1 silver
9 AH64-02218B DOOR-CASS.R ABS L/GRAY 1 gray
AH64-02218C ABS L/GRAY 1 silver
10 AH67-00196B LENS-JOG PMMA BLUE 1
11 AH63-00544A SHEET-JOG 3M 1
12 AH64-02234B KNOB-JOG ABS L/GRAY 1 gray
13 AH64-02224B DECO-JOG ABS L/GRAY 1
14 AH64-02222B DECO-FUNCTION ABS L/GRAY 1 mp3
AH64-02222C ABS L/GRAY 1
15 AH64-02223B DECO-FRONT ABS L/GRAY 1 RDS(silver)
AH64-02223C ABS L/GRAY 1 NO RDS(silver)
AH64-02223D ABS L/GRAY 1 RDS(gray)
AH64-02223E ABS L/GRAY 1 NO RDS(gray)
16 AH64-02279B KNOB-MIC ABS L/GRAY 1 silver
17 AH61-00552A SPRING-EJECT L SUS PI 1.1 1
18 AH64-02231B KNOB-VOLUME ABS L/GRAY 1
19 AH67-00193B LENS-VOLUME PMMA GLUE 1
20 AH64-02232B KNOB-SUBWOOFER ABS L/GRAY 2 silver
21 AH67-00194B LENS-SUBWOOFER PMMA BLUE 2
22 AH61-00553A SPRING-EJECT R SUS PI 1.1 1
23 AH61-80030A DAMPER-ASSY POM M0.8 G130 2
24 AH95-50001A ASSY-LATCH ASSY 2
25 AH64-02230B KNOB-DEMO ABS L/GRAY 1 silver
AH64-02230C ABS L/GRAY 1 gray
26 AH67-00190B LENS-P.SOUND PMMA RED 1 ZS750/ZS730
27 AH61-01253A HOLDER-P.SOUND ABS WHITE 1
28 AH64-02226B KNOB-OPEN ABS L/GRAY 1 silver
29 AH61-01254A HOLDER-FUNCTION ABS WHITE 1
30 AH63-00505A FILTER-FUNCTION PC 0.16T MILKY 1
31 AH67-00191B LENS-FUNCTION PMMA BLUE 1
32 AH67-00192A LENS-POWER PMMA MILKY 1
33 AH64-02228B KNOB-POWER ABS L/GRAY 1 silver
34 AH64-02229B KNOB-ECHO ABS L/GRAY 1 silver
35 AH64-02227B KNOB-TIMER ABS L/GRAY 1 silver
36 AH64-00900A CABINET-SIDE.L MIPS L/GRAY 1 silver
AH64-00900B MIPS D/GRAY 1 gray
37 AH64-30443F CABINET-TOP MIPS L/GRAY 1 silver
AH64-30443G MIPS D/GRAY 1 gray
38 AH61-40014A SUPPORT-RIVET NYLON 66 BLK 1
39 AH61-00021B SUPPORT-PCB ABS BLK 1
40 AH63-000278E COVER-PCB PC 1
41 AH61-40014A SUPPORT-RIVET NYLON 66 BLK 1
42 AH61-00685A BRKT-PCB SECC 0.8T 1
43 6501-001391 CABLE-TYE NYLON 66 1
44 AH62-00078A HEAT-SINK TR AL EXTR 1
45 AH64-01036B COVER-REAR ABS L/GRY 1
46 AH64-01721C CABINET-REAR HIPS L/GRAY 1 RDS
AH64-01721D HIPS L/GRAY 1 NO RDS
47 AH62-00080B HEAT-SINK.M AL EXTR 1 ZS750
AH62-00080C AL EXTR 1 ZS730
48 AH61-00973A BRKT-H/SINK L SECC 1.0T 1
49 AH61-00977A BRKT-H/SINK R SECC 1.0T 1
50 AH64-30416E CABINET-BOTTOM SECC 1.0T 1
51 AH61-00413B BRKT-DECK SPTE 0.3T 1
52 AH64-00901A CABINET-SIDE.R MIPS L/GRAY 1 silver
AH64-00901B MIPS D/GRAY 1 gray
53 AH61-00521A HOLDER-VFD ABS BLK 1
