9
<MCU-S1NEK1N>
ø 22.22 (ø 7/8)
ø 19.05 (ø 3/4)
ø 9.52 (ø 3/8)
ø 9.52 (ø 3/8) WELDING
ø 15.88 (ø 5/8) WELDING
Liquid pipe connected to indoor unit
Gas pipe connected to indoor unit
<MCU-S12NEK1N, MCU-S8NEK1N>
ø 9.52 (ø 3/8) WELDING
Φ15.88 (Φ5/8)
ø 28.58 (ø 1 1/8)
ø 28.58 (ø 1 1/8)
ø 15.88 (ø 5/8) WELDING
Liquid pipe connected to indoor unit
Gas pipe connected to indoor unit
