2
Preparation for Installation
Unit : mm(inch)
450(17.71)
105(4.13)
120(4.72)
100(3.93)
100(3.93)
50
(1.96)
380
(14.96)
190(7.48)
333(13.11)
Inspection area
549(21.61)
500(19.68)
458(18.03)
403(15.86)
97(3.81)
74(2.91)
85(3.34)
204(8.03)
40(1.57) 40(1.57)
323(12.71)
313(12.32)
Inspection area
