Connection using a cross LAN cable



The appearance may differ depending on the product.



Multiple products can be connected using the RS232C IN / OUT port on the product.

Monitor 1

Monitor 2

Computer

RS232C OUT

RS232C IN

RJ45 (LAN OUT)
